OEM#: 4YU30New OEM Original Outright

BELT DRIVE MOTOR, 1 SPEED, OPEN DRIPPROOF, CRADLE BASE MOUNT, 1 HP, 115/208-230V AC by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$536.18 each
$590.49 Savings: $54.31 (9%)
Ready to ship
HomeDAYTON ELECTRIC MANUFACTURING CO4yu30
BELT DRIVE MOTOR, 1 SPEED, OPEN DRIPPROOF, CRADLE BASE MOUNT, 1 HP, 115/208-230V AC by DAYTON ELECTRIC MANUFACTURING CO
BELT DRIVE MOTOR, 1 SPEED, OPEN DRIPPROOF, CRADLE BASE MOUNT, 1 HP, 115/208-230V AC by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 4YU30
BELT DRIVE MOTOR, 1 SPEED, OPEN DRIPPROOF, CRADLE BASE MOUNT, 1 HP, 115/208-230V AC by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$536.18 each
$590.49 Savings: $54.31 (9%)

BELT DRIVE MOTOR, SINGLE PHASE, MOTOR DESIGN CAPACITOR-START, 1 HP, NAMEPLATE RPM 1,725, NO. OF SPEEDS 1, VOLTAGE 115/208-230V AC, 12.8/6.4-6.4 A FULL LOAD AMPS, 56 FRAME, USABLE @ 208V YES, USABLE @ 200V NO, 60 HZ HZ, MOTOR SERVICE FACTOR 1.15, MOTOR THERMAL PROTECTION AUTO, INS. CLASS B, MAX. AMBIENT TEMP. 104 DEGREES F, DUTY CYCLE CONTINUOUS, MOTOR SHAFT ROTATION CW/CCW, MOTOR ENCLOSURE DESIGN OPEN DRIPPROOF, MOTOR MOUNTING TYPE CRADLE BASE, M

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4YU30 Key Specs
Item
BELT DRIVE MOTOR, 1 SPEED, OPEN DRIPPROOF, CRADLE BASE MOUNT, 1 HP, 115/208-230V AC
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4YU30
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Dia.
6-1/2 in
Country of Origin
USA
Duty Cycle
Continuous
Frame
56
Full Load Amps
12.8/6.4-6.4 A
HP
1
Hz
60 Hz
Includes
Capacitor
Ins. Class
B
Length Less Shaft
9-1/2 in
Max. Ambient Temp.
104 °F
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Cradle Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Nameplate RPM
1,725
No. of Speeds
1
Phase
Single
RPM Range
1,701-1,800
Resilient Ring Dia.
2-1/2 in
Ring to Ring Center
9-1/8 in
Shaft Dia.
5/8 in
Shaft Length
1-7/8 in
Standards
CSA Certified; UL Recognized
Usable @ 200V
No
Usable @ 208V
Yes
Voltage
115/208-230V AC
