OEM#: 4VAF9New OEM Original Outright
MOTOR SP PH 1/4 HP 1725 115/208-230V 48Y by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$354.64 each
OEM#: 4VAF9MOTOR SP PH 1/4 HP 1725 115/208-230V 48Y by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$354.64 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4VAF9 Key Specs
Item
MOTOR SP PH 1/4 HP 1725 115/208-230V 48Y
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4VAF9
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
5-5/8 in
Country of Origin
Mexico
Duty
Continuous
Frame
48Y
Full Load Amps
5.1/2.4-2.6
HP
1/4 in
Hz
60
Ins. Class
B
Length Less Shaft
7-7/8 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Cradle Base
Motor Service Factor
1.15
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Belt Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1725
Nominal Efficiency
62 %
Number of Speeds
1
Overall Length
9-13/16 in
Phase
1
Resilient Ring Diameter
2-1/4 in
Ring to Ring Center
7-7/16 in
Shaft Diameter
1/2 in
Shaft Length
1-7/8 in
Standards
CSA Certified (258501), UL Recognized (E37403)
Voltage
115/208-230
Voltage Compatibility
115, 115/208-230, 115/230, 120, 120/240, 208, 208-230, 208-240, 230, 240
