OEM#: 4UX59New OEM Original Outright

PEDESTAL FAN MOTOR, SINGLE PHASE, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, 1/2 HP, NAMEPLATE RPM 825, NO. OF SPEEDS 1, VOLTAGE 115V AC, 6.4 A by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$360.32 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO4ux59
PEDESTAL FAN MOTOR, SINGLE PHASE, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, 1/2 HP, NAMEPLATE RPM 825, NO. OF SPEEDS 1, VOLTAGE 115V AC, 6.4 A by DAYTON ELECTRIC MANUFACTURING CO
PEDESTAL FAN MOTOR, SINGLE PHASE, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, 1/2 HP, NAMEPLATE RPM 825, NO. OF SPEEDS 1, VOLTAGE 115V AC, 6.4 A by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 4UX59
PEDESTAL FAN MOTOR, SINGLE PHASE, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, 1/2 HP, NAMEPLATE RPM 825, NO. OF SPEEDS 1, VOLTAGE 115V AC, 6.4 A by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$360.32 each

PEDESTAL FAN MOTOR, SINGLE PHASE, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, 1/2 HP, NAMEPLATE RPM 825, NO. OF SPEEDS 1, VOLTAGE 115V AC, 6.4 A FULL LOAD AMPS, 48YZ FRAME, 60 HZ HZ, MOTOR SERVICE FACTOR 1, MOTOR THERMAL PROTECTION AUTO, INS. CLASS B, DUTY CYCLE CONTINUOUS, MAX. AMBIENT TEMP. 40 DEGREES C, MOTOR SHAFT ROTATION CW/CCW, MOTOR ENCLOSURE DESIGN TOTALLY ENCLOSED AIR-OVER, MOTOR MOUNTING POSITION HORIZONTAL, SHAFT LENGTH 1 7/8 IN, SHAFT DI

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4UX59 Key Specs
Item
PEDESTAL FAN MOTOR, SINGLE PHASE, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, 1/2 HP, NAMEPLATE RPM 825, NO. OF SPEEDS 1, VOLTAGE 115V AC, 6.4 A
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4UX59
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
10 ft Cord & Pull Chain Switch
No
Ambient Temperature
40 Degrees C
Application
Air Circulators where Motor is Mounted Directly to Fan Column, Also Used on Exhaust Fans, Unit Heaters and Other Air-moving Uses
Body Diameter
5-5/8 in
Capacitor Required
Included
Duty
Continuous
Frame
48YZ
Full Load Amps
6.4
HP
1/2
Hz
60
Ins. Class
B
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Mounting Type
Yoke
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Pedestal Fans
Motor Thermal Protection
Auto
Nameplate RPM
825
Number of Speeds
1
Overall Length
10 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA Certified, UL Recognized
Voltage
115
