OEM#: 4M207New OEM Original Outright
CONDENSER FAN MOTOR 1/2 HP 1075 RPM 60HZ by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$235.60 each
OEM#: 4M207CONDENSER FAN MOTOR 1/2 HP 1075 RPM 60HZ by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$235.60 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4M207 Key Specs
Item
CONDENSER FAN MOTOR 1/2 HP 1075 RPM 60HZ
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4M207
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Fan/Blower
Body Diameter
5-5/8 in
Bolt Circle Diameter
5-1/8 in
Capacitor Required
2MDV6
Duty
Continuous
Frame
48YZ
Full Load Amps
3.1-3.1
HP
1/2
Hz
60
Ins. Class
B
Lead Length
30 in
Length Less Shaft
6-5/8 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Number of Speeds
1
Overall Length
10-5/16 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
6 in
Standards
CSA Certified (225293), UL Recognized (E37403)
Stud Quantity
4
Stud Size
8-32 NC-2A
Voltage
208-230
