OEM#: 4CVX2New OEM Original Outright

AC GEARMOTOR, NUMBER OF OUTPUT SHAFTS 1, MOTOR TYPE 3-PHASE, MOTOR ENCLOSURE TOTALLY ENCLOSED FAN-COOLED, NAMEPLATE SPEED 68 RPM, MAXIMUM TO by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$1,952.98 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO4cvx2
AC GEARMOTOR, NUMBER OF OUTPUT SHAFTS 1, MOTOR TYPE 3-PHASE, MOTOR ENCLOSURE TOTALLY ENCLOSED FAN-COOLED, NAMEPLATE SPEED 68 RPM, MAXIMUM TO by DAYTON ELECTRIC MANUFACTURING CO
AC GEARMOTOR, NUMBER OF OUTPUT SHAFTS 1, MOTOR TYPE 3-PHASE, MOTOR ENCLOSURE TOTALLY ENCLOSED FAN-COOLED, NAMEPLATE SPEED 68 RPM, MAXIMUM TO by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 4CVX2
AC GEARMOTOR, NUMBER OF OUTPUT SHAFTS 1, MOTOR TYPE 3-PHASE, MOTOR ENCLOSURE TOTALLY ENCLOSED FAN-COOLED, NAMEPLATE SPEED 68 RPM, MAXIMUM TO by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$1,952.98 each

AC GEARMOTOR, NUMBER OF OUTPUT SHAFTS 1, MOTOR TYPE 3-PHASE, MOTOR ENCLOSURE TOTALLY ENCLOSED FAN-COOLED, NAMEPLATE SPEED 68 RPM, MAXIMUM TORQUE 796 IN-LB, OVERHUNG LOAD CAPACITY 882 FT-LB, ROTATION CW/CCW, OUTPUT SHAFT HEIGHT 3.25 IN, MOUNTING ORIENTATION ANY ANGLE, OPERATING VOLTAGE 208-230/460V AC, GEAR RATIO 26:1, BRAKE TYPE NONE, OUTPUT LOCATION LEFT HAND, SHAFT ORIENTATION RIGHT ANGLE, MOTOR INSULATION CLASS F, COMPATIBLE CAPACITOR MANUFACT

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4CVX2 Key Specs
Item
AC GEARMOTOR, NUMBER OF OUTPUT SHAFTS 1, MOTOR TYPE 3-PHASE, MOTOR ENCLOSURE TOTALLY ENCLOSED FAN-COOLED, NAMEPLATE SPEED 68 RPM, MAXIMUM TO
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4CVX2
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Printing Press, Conveyors, Pumps, Mixers
Bearings
Ball
Country of Origin
China
Full Load Amps
3.4-3.4/1.7
Gear Case Material
Die Cast Aluminum
Gear Material
Hardened Steel/Forged Bronze
Gear Ratio
26:1
Gearmotor Brake Type
None
Gearmotor Enclosure
Totally Enclosed Fan-Cooled
Gearmotor Mounting Position
All Angle
Gearmotor Phase
3
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Right Angle
Gearmotor Shaft Type
Single Left
Gearmotor Type
AC Gearmotor
Gearmotor Voltage
208-230/460 V AC
Gears
Hardened Steel Worm, Forged Bronze Output Gear
Housing
Aluminum/Cast Iron
Hz
60/50 Hz
Input HP
1 hp
Insulation Class
F
Keyway Size Type
1/4 sq in x 1-1/4 in
Lubrication
Gear Oil
Max. Ambient Temp.
40 Degrees C
Max. Torque
796.0 in-lb
Motor Type
3-Phase
Nameplate RPM
68 RPM
Overall Length
16.25 in
Overhung Load
882 lb
Seals
Oil Seals on Axle Shaft
Shaft Dia. (Dimension U)
1"
Shaft Length (Dimension V)
2.25"
Standards
UL Recognized/CSA
Starting Torque
2,600 in-lb
Thermal Protection
None
