OEM#: 4M206New OEM Original Outright

CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$213.56 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO4M206
CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO by DAYTON ELECTRIC MANUFACTURING CO
CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 4M206
CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$213.56 each

CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATION CW/CCW, 48YZ FRAME, MOTOR ENCLOSURE DESIGN TOTALLY ENCLOSED AIR-OVER, STUD MOTOR MOUNTING TYPE, MOTOR MOUNTING POSITION ALL ANGLE, SHAFT DIA. 1/2 IN, SHAFT LENGTH 6 IN, MOTOR THERMAL PROTECTION AUTO, MAX. AMBIENT TEMP. 60 DEGREES C, NAMEPLATE RPM 1,075, HVAC/R, CONDENSER FAN, 60 HZ, FULL LOAD AMPS 2.0-2.0 A

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4M206 Key Specs
Item
CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4M206
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Direct-Drive Blower
Body Diameter
5-5/8 in
Bolt Circle Diameter
5-1/8 in
Capacitor Required
2MDV6
Duty
Continuous
Frame
48YZ
Full Load Amps
2-2
HP
1/3
Hz
60
Ins. Class
B
Lead Length
30 in
Length Less Shaft
6-3/8 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Number of Speeds
1
Overall Length
10-1/16 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
6 in
Standards
CSA Certified (258501), UL Recognized (E47479)
Stud Quantity
4
Stud Size
8-32 NC-2A x 3/4 in
Voltage
208-230
