OEM#: 4K259New OEM Original Outright

MOTOR 1/2 HP 1725 RPM 115/208-230 V by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$385.69 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO4K259
MOTOR 1/2 HP 1725 RPM 115/208-230 V by DAYTON ELECTRIC MANUFACTURING CO
MOTOR 1/2 HP 1725 RPM 115/208-230 V by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 4K259
MOTOR 1/2 HP 1725 RPM 115/208-230 V by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$385.69 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4K259 Key Specs
Item
MOTOR 1/2 HP 1725 RPM 115/208-230 V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4K259
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
5-5/8 in
Duty
Continuous
Frame
48Z
Full Load Amps
8.6/4.2-4.3
HP
1/2
Hz
60
Ins. Class
B
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Cradle Base
Motor Service Factor
1.25
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Belt Drive Fan/Blower
Motor Thermal Protection
Auto
Nameplate RPM
1725
Number of Speeds
1
Phase
1
Shaft Diameter
1/2 in
Shaft Length
1-7/8 in
Standards
UL Recognized, CSA Certified
Voltage
115/208-230
Voltage Compatibility
115, 115/208-230, 115/230, 120, 120/240, 208, 208-230, 208-240, 230, 240
