OEM#: 3N350New OEM Original Outright

MTR 3 PH 1/3HP 1725 208-230/460 EFF 72.0 by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$318.62 each
$375.75 Savings: $57.13 (15%)
Ready to ship
HomeDAYTON ELECTRIC MANUFACTURING CO3n350
MTR 3 PH 1/3HP 1725 208-230/460 EFF 72.0 by DAYTON ELECTRIC MANUFACTURING CO
MTR 3 PH 1/3HP 1725 208-230/460 EFF 72.0 by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 3N350
MTR 3 PH 1/3HP 1725 208-230/460 EFF 72.0 by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$318.62 each
$375.75 Savings: $57.13 (15%)
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 3N350 Key Specs
Item
MTR 3 PH 1/3HP 1725 208-230/460 EFF 72.0
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
3N350
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Duty
Continuous
Frame
48
Full Load Amps
1.3-1.3/0.7
HP
1/3
Hz
60
Ins. Class
B
Inverter Rated
Yes
Length Less Shaft
8-1/2 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
Premium Efficient
Motor Enclosure Design
Totally Enclosed Nonventilated
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
72 %
Number of Speeds
1
Overall Length
10-1/16 in
Phase
3
Shaft Diameter
1/2 in
Shaft Length
1-1/2 in
Standards
CSA (258501), UL (E47479)
Voltage
208-230/460
