OEM#: 3LU77New OEM Original Outright

MOTOR 1/3HP D/D BLOWER by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$285.46 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO3lu77
MOTOR 1/3HP D/D BLOWER by DAYTON ELECTRIC MANUFACTURING CO
MOTOR 1/3HP D/D BLOWER by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 3LU77
MOTOR 1/3HP D/D BLOWER by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$285.46 each

DIRECT DRIVE BLOWER MOTOR, SINGLE PHASE, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, 1/3 HP, NAMEPLATE RPM 1,625, NO. OF SPEEDS 3, VOLTAGE 115V AC, FULL LOAD AMPS 5.1 A, 48YZ FRAME, MOTOR THERMAL PROTECTION AUTO, 60 HZ HZ, MOTOR SERVICE FACTOR 1, INS. CLASS B, MOTOR SHAFT ROTATION CW/CCW, MAX. AMBIENT TEMP. 40 DEGREES C, DUTY CYCLE CONTINUOUS, MOTOR ENCLOSURE DESIGN OPEN AIR-OVER, MOTOR MOUNTING TYPE RING/STUD, MOTOR MOUNTING POSITION ALL ANGLE

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 3LU77 Key Specs
Item
MOTOR 1/3HP D/D BLOWER
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
3LU77
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Blowers, Fans and Air Circulators
Body Diameter
5-5/8 in
Bolt Circle Diameter
5-1/8 in
Capacitor Required
2MDV9
Country of Origin
China
Duty
Continuous
Frame
48YZ
Full Load Amps
5.1
HP
1/3
Hz
60
Includes
Kit for 2.5 in Hub Ring Assembly
Ins. Class
B
Length Less Shaft
5-11/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Sleeve
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Ring/Stud
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1625
Number of Speeds
3
Overall Length
11-11/16 in
Phase
1
Resilient Ring Diameter
2-1/4 in
Ring to Ring Center
5-1/4 in
Shaft Diameter
1/2 in
Shaft Length
6 in
Standards
CSA Certification (258501), UL Recognition (E37403)
Voltage
115
Voltage Compatibility
115, 115/208-230, 115/230, 120, 120/240
