OEM#: 3M265New OEM Original Outright

CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$261.52 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO3M265
CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO by DAYTON ELECTRIC MANUFACTURING CO
CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 3M265
CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$261.52 each

CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATION CW/CCW, 48YZ FRAME, MOTOR ENCLOSURE DESIGN OPEN AIR-OVER, CRADLE BASE MOTOR MOUNTING TYPE, MOTOR MOUNTING POSITION HORIZONTAL OR VERTICAL SHAFT UP, SHAFT DIA. 1/2 IN, SHAFT LENGTH 6 IN, MOTOR THERMAL PROTECTION AUTO, MAX. AMBIENT TEMP. 60 DEGREES C, NAMEPLATE RPM 1,625, HVAC/R, CONDENSER FAN, 60 HZ, FULL LO

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 3M265 Key Specs
Item
CONDENSER FAN MOTOR, MOTOR DESIGN PERMANENT SPLIT CAPACITOR, PHASE SINGLE, 1/3 HP, NO. OF SPEEDS 1, VOLTAGE 208-230V AC, MOTOR SHAFT ROTATIO
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
3M265
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Condenser Fan
Body Diameter
5-5/8 in
Bolt Circle Diameter
5-1/8 in
Capacitor Required
Included
Duty
Continuous
Frame
48YZ
Full Load Amps
3.1
HP
1/3
Hz
60
Includes
Capacitor
Ins. Class
B
Lead Length
30 in
Length Less Shaft
5-5/8 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Sleeve
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
Horizontal or Vertical Shaft Up
Motor Mounting Type
Cradle Base
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1625
Nominal Efficiency
67.5 %
Number of Speeds
1
Overall Length
11-11/16 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
6 in
Standards
CSA Certified (258501), UL Recognized (E37403)
Stud Quantity
4
Stud Size
8-32 UNF-2A x 1 in (Shaft-End)
Voltage
208-230
