OEM#: 3LU91New OEM Original Outright
MOTOR 1HP D/D BLOWER by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$342.34 each
OEM#: 3LU91MOTOR 1HP D/D BLOWER by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$342.34 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 3LU91 Key Specs
Item
MOTOR 1HP D/D BLOWER
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
3LU91
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Blowers, Fans and Air Circulators
Body Diameter
5-5/8 in
Bolt Circle Diameter
5-1/8 in
Capacitor Required
2MDW2
Duty
Continuous
Frame
48YZ
Full Load Amps
15.8
HP
1
Hz
60
Includes
Kit for 2.5 in Hub Ring Assembly
Ins. Class
B
Length Less Shaft
7-7/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Sleeve
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Ring/Stud
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Number of Speeds
4
Overall Length
13-7/16 in
Phase
1
Resilient Ring Diameter
2-1/4 in
Ring to Ring Center
7 in
Shaft Diameter
1/2 in
Shaft Length
6 in
Standards
CSA Certification (258501), UL Recognition (E37403)
Voltage
115
Voltage Compatibility
115, 115/208-230, 115/230, 120, 120/240
