OEM#: 31TT12New OEM Original Outright

MTR 3PH 1HP 1725 230/4600V EFF 83.5 by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$837.29 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO31TT12
MTR 3PH 1HP 1725 230/4600V EFF 83.5 by DAYTON ELECTRIC MANUFACTURING CO
MTR 3PH 1HP 1725 230/4600V EFF 83.5 by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 31TT12
MTR 3PH 1HP 1725 230/4600V EFF 83.5 by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$837.29 each

GENERAL PURPOSE MOTOR, THREE PHASE, MOTOR DESIGN 3-PHASE, 1 HP, NAMEPLATE RPM 1,725, NO. OF SPEEDS 1, VOLTAGE 230/460V AC, FULL LOAD AMPS 3.0/1.5 A, 56 FRAME, HZ 60/50 HZ, MOTOR SERVICE FACTOR 1.15, MAX. AMBIENT TEMP. 104 DEGREES F, MOTOR THERMAL PROTECTION NONE, DUTY CYCLE CONTINUOUS, INS. CLASS B, MOTOR ENCLOSURE DESIGN OPEN DRIPPROOF, MOTOR SHAFT ROTATION CW/CCW, MOTOR MOUNTING TYPE RIGID BASE, MOTOR MOUNTING POSITION ALL ANGLE, INVERTER RATED

Ready to ship
Asset Information
warning

WARNING: This product can expose you to chemicals known to the State of California to cause cancer and reproductive harm.

Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 31TT12 Key Specs
Item
MTR 3PH 1HP 1725 230/4600V EFF 83.5
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
31TT12
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous
Frame
56
Full Load Amps
3/1.5
Green Certification or Other Recognition
Energy Aware Certified
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
HP
1 hp
Hz
60/50
Ins. Class
B
Inverter Rated
Yes
Length Less Shaft
9-3/4 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
83.5 %
Number of Speeds
1
Overall Length
11-11/16 in
Phase
3
RPM Group
1701-1800
RPM Range
1701-1800
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
UL Recognized for US and Canada (E47479)
Voltage
230/460
