OEM#: 2LY96New OEM Original Outright

LIGHT DTY INDSTRL FAN 20 BLDE DIA 2SPD by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$301.49 each
$331.27 Savings: $29.78 (9%)
Ready to ship
HomeDAYTON ELECTRIC MANUFACTURING CO2ly96
LIGHT DTY INDSTRL FAN 20 BLDE DIA 2SPD by DAYTON ELECTRIC MANUFACTURING CO
LIGHT DTY INDSTRL FAN 20 BLDE DIA 2SPD by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 2LY96
LIGHT DTY INDSTRL FAN 20 BLDE DIA 2SPD by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$301.49 each
$331.27 Savings: $29.78 (9%)
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 2LY96 Key Specs
Item
LIGHT DTY INDSTRL FAN 20 BLDE DIA 2SPD
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
2LY96
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Air Flow
2,600/3,700 cfm
Air Velocity @ 10 Ft.
800/550 fpm
Air Velocity @ 20 Ft.
518/436 fpm
Air Velocity @ 40 Ft.
200/190 fpm
Air Velocity @ 60 Ft.
150/130 fpm
Amps
2.0/1.5
Assembly
Assembly Required
Base Dia.
27 in
Bearing Type
Ball
Blade Diameter
20 in
Blade Material
Aluminum
Color
Black
Depth
27 in
Drive Type
Direct Drive
Environmental Applications
Industrial
Fan Cord Length
9 ft
Fan Housing Material
Steel
Fan Mounting Location
Pedestal
Guard Material
Steel
Height
75 in
Height Adjustment
57 to 75 in
Hz
60 Hz
Includes
Column, Mounting Hardware, Pedestal
Max. Ambient Temp.
104 Degrees F
Motor Enclosure
Open Air-Over
Motor HP
1/6 hp
Motor Insulation
Class B
Motor Type
Permanent Split Capacitor
NEMA Plug Configuration
5-15P
Number of Blades
3
Number of Conductors
3
Number of Speeds
2
Oscillation
Non-Oscillating
Phase
1
RPM
1200/1000
Shaft Dia.
12 mm
Sound Level
72 dBA
Standards
cULus Listed
Thermal Protection
Automatic Reset
Voltage
120V AC
Watts
240/180
Wheeled Base
Stationary
Width
24 in
Wire Guard Finish
Polyester Powder Coated Black
