OEM#: 2H598New OEM Original Outright
AC GEARMOTOR 63 RPM OPEN 115V by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$893.54 each
OEM#: 2H598AC GEARMOTOR 63 RPM OPEN 115V by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$893.54 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 2H598 Key Specs
Item
AC GEARMOTOR 63 RPM OPEN 115V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
2H598
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearings
Needle Throughout, Ball on Motor
Full Load Amps
1.05
Gear Case Material
Die Cast Aluminum
Gear Material
Hardened Steel
Gear Ratio
25:1
Gear Type
Helical First Stage/Subsequent Stages Spur
Gearmotor Brake Type
None
Gearmotor Enclosure
Open
Gearmotor Mounting Position
All Angle
Gearmotor Phase
1
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Parallel
Gearmotor Shaft Type
Single
Gearmotor Type
AC Gearmotor
Gearmotor Voltage
115V AC
Gears
Hardened Steel, 1st Stage Helical, Subsequent Stages Spur
Housing
Die Cast Aluminum
Hz
60 Hz
Input HP
1/10 hp
Length Less Shaft
7 1/2 in
Lubrication
Permanent Heavy Fluid Gear Oil
Max. Ambient Temp.
40 Degrees C
Max. Torque
90.0 in-lb
Motor Type
PSC
Nameplate RPM
63 RPM
Overhung Load
230 lb
Seals
Spring Loaded Lip Type on Input and Output Shaft
Shaft Dia. (Dimension U)
1/2"
Shaft Length (Dimension V)
1"
Standards
UL Recognized, C-UL Recognized
Thermal Protection
None
