Repair

115VAC 50/60HZ 5.1A 1875RPM RECTANGULAR SHADED POLE OEM SPECIALTY BLOWER

115VAC 50/60HZ 5.1A 1875RPM RECTANGULAR SHADED POLE OEM SPECIALTY BLOWER
115VAC 50/60HZ 5.1A 1875RPM RECTANGULAR SHADED POLE OEM SPECIALTY BLOWER

115VAC 50/60HZ 5.1A 1875RPM RECTANGULAR SHADED POLE OEM SPECIALTY BLOWER

Product Overview

Featuring all-position mounting, this dynamically balanced blower provides smooth and quiet operation. Noise and vibration are held to a minimum to maintain CFM at higher static pressures. The motor has cast-aluminum end shields for greater heat dissipation and protection, resulting in less downtime and longer service life.

Technical Specs
P/N: 2C647A Key Specs
Item
115VAC 50/60HZ 5.1A 1875RPM RECTANGULAR SHADED POLE OEM SPECIALTY BLOWER
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
2C647A
Returnable
No
Warranty
Bearing Type
Ball
Drive Type
Direct
Finish
Baked Enamel
Flow Rate
176cfm
Frequency Range
50/60Hz
Full Load Current
5.1A
Inlet Diameter
4-1/2in
Lead Length
37in
Material
Steel
Maximum Inlet Temprature
104°F
Motor Enclosure
Totally Enclosed
Motor Insulation
Class B
Mounting Position
All Position
Number of Phases
1
Outlet Dimensions
3 W x 3-1/8in H
Overall Dimensions
6-3/16 W x 7-7/16 D x 8in H
Product Type
Blower
Speed Range
1875RPM
Type
Rectangular, Shaded Pole, OEM Specialty
Voltage Rating
115VAC
Wheel Diameter
5-1/4in
Wheel Type
Forward Curve
Wheel Width
2-1/2in
With
With Flange

Featuring all-position mounting, this dynamically balanced blower provides smooth and quiet operation. Noise and vibration are held to a minimum to maintain CFM at higher static pressures. The motor has cast-aluminum end shields for greater heat dissipation and protection, resulting in less downtime and longer service life.
