OEM#: 1YBV8BGNew OEM Original Outright
AG FAN MTR SPLT PH TEAO 1/2HP 1725RPM by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$445.94 each
OEM#: 1YBV8BGAG FAN MTR SPLT PH TEAO 1/2HP 1725RPM by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$445.94 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 1YBV8BG Key Specs
Item
AG FAN MTR SPLT PH TEAO 1/2HP 1725RPM
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
1YBV8BG
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous Air Over
Finish
Farm Duty Green
Frame
56
Full Load Amps
7.6/3.8
HP
1/2
Hz
60
Includes
Gasketed Wiring Compartment Cover, Shaft Key, Shaft Slinger
Ins. Class
B
Item - Farm Duty Motors
Agricultural Fan Motor
Length Less Shaft
8-11/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
Farm Duty
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Poultry/Livestock Belt Drive Fan
Motor Thermal Protection
Auto
Nameplate RPM
1725
Nominal Efficiency
68.7 %
Overall Length
10-5/8 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-15/16 in
Standards
CSA Certified (258501), UL Recognized (E37403)
Voltage
115/230
Voltage Compatibility
115, 115/230, 120, 120/240, 230, 240
