OEM#: 1LPU7New OEM Original Outright
AC GEARMOTOR 7 RPM TENV 115/230V by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$606.83 each
OEM#: 1LPU7AC GEARMOTOR 7 RPM TENV 115/230V by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$606.83 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 1LPU7 Key Specs
Item
AC GEARMOTOR 7 RPM TENV 115/230V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
1LPU7
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Approvals, Certifications & Standards
UL Recognized, C-UL Recognized, CE Certified
Bearings
Porous Bronze Sleeve on Case, Ball on Motor
Capacitor Required
Included
Finish
Unpainted
Full Load Amps
0.62/0.33
Gear Case Material
Die Cast Zinc
Gear Material
Acetyl/Steel
Gear Ratio
239:1
Gearmotor Brake Type
None
Gearmotor Enclosure
Totally Enclosed Nonventilated
Gearmotor Mounting Position
All Angle
Gearmotor Phase
1
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Parallel
Gearmotor Shaft Type
Single
Gearmotor Type
AC Gearmotor
Gearmotor Voltage
115/230V AC
Gears
Acetyl/Steel
Housing
Die Cast Zinc
Hz
60/50 Hz
Input HP
1/20 hp
Insulation Class
B
Keyway Size Type
Flat
Length Less Shaft
6 1/8 in
Lubrication
Grease Filled
Maximum Ambient Temperature
40 Degrees C
Maximum Torque
50.0 in-lb
Motor Type
PSC
Nameplate RPM
7 RPM
Overhung Load
50 lb
RPM @ 50 Hz
6
Reversible Shaft Output
No
Seals
O-Ring Type on Output Shaft
Shaft Diameter (Dimension U)
5/16"
Shaft Length (Dimension V)
0.75"
Thermal Protection
None
