OEM#: 1LPK8New OEM Original Outright

DC GEARMOTOR, SHAFT ORIENTATION PARALLEL, MOTOR ENCLOSURE TOTALLY ENCLOSED NONVENTILATED, OPERATING VOLTAGE 90V DC, MOTOR TYPE PERMANENT MAG by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$714.40 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO1LPK8
DC GEARMOTOR, SHAFT ORIENTATION PARALLEL, MOTOR ENCLOSURE TOTALLY ENCLOSED NONVENTILATED, OPERATING VOLTAGE 90V DC, MOTOR TYPE PERMANENT MAG by DAYTON ELECTRIC MANUFACTURING CO
DC GEARMOTOR, SHAFT ORIENTATION PARALLEL, MOTOR ENCLOSURE TOTALLY ENCLOSED NONVENTILATED, OPERATING VOLTAGE 90V DC, MOTOR TYPE PERMANENT MAG by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 1LPK8
DC GEARMOTOR, SHAFT ORIENTATION PARALLEL, MOTOR ENCLOSURE TOTALLY ENCLOSED NONVENTILATED, OPERATING VOLTAGE 90V DC, MOTOR TYPE PERMANENT MAG by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$714.40 each

DC GEARMOTOR, SHAFT ORIENTATION PARALLEL, MOTOR ENCLOSURE TOTALLY ENCLOSED NONVENTILATED, OPERATING VOLTAGE 90V DC, MOTOR TYPE PERMANENT MAGNET DC, NAMEPLATE SPEED 13 RPM, MAXIMUM TORQUE 250 IN-LB, OVERHUNG LOAD CAPACITY 250 FT-LB, ROTATION CW/CCW, MOUNTING ORIENTATION ANY ANGLE, GEAR RATIO 135:1, INPUT HORSEPOWER 1/15 HP, OUTPUT SHAFT DIAMETER 3/4 IN, BEARING TYPE BALL ON MOTOR, POROUS BRONZE SLEEVE ON CASE

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 1LPK8 Key Specs
Item
DC GEARMOTOR, SHAFT ORIENTATION PARALLEL, MOTOR ENCLOSURE TOTALLY ENCLOSED NONVENTILATED, OPERATING VOLTAGE 90V DC, MOTOR TYPE PERMANENT MAG
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
1LPK8
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearings
Ball on Motor, Porous Bronze Sleeve on Case
Brushes
Externally Replaceable
Country of Origin
USA
Finish
Unpainted
Full Load Amps
0.84 A
Gear Case
Die Cast Zinc
Gear Material
Hardened Steel/Phenolic
Gear Ratio
135:1
Gearmotor Enclosure
Totally Enclosed Nonventilated
Gearmotor Mounting Position
All Angle
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Parallel
Gearmotor Shaft Type
Single
Gearmotor Type
DC Gearmotor
Gearmotor Voltage
90V DC
Housing Material
Die Cast Zinc
Input HP
1/15
Insulation Class
F
Keyway Size Type
#605 Woodruff Key
Length Less Shaft
8 1/2 in
Lubrication
Grease Filled
Max. Ambient Temp.
40 Degrees C
Max. Torque
250.0 in-lb
Motor Type
Permanent Magnet DC
Nameplate RPM
13 RPM
Overall Length
10 in
Overhung Load
250 lb
Rear Shaft Encoder/Pulse Generator Mounting
No
Replacement Brushes
6YHY6
Reversible Shaft Output
No
Seals
O-Ring Type on Output Shaft
Shaft Dia. (Dimension U)
3/4"
Shaft Length (Dimension V)
1-1/2"
Standards
C-UL Recognized, UL Recognized
Thermal Protection
None
