OEM#: 1AHD4New OEM Original Outright
CABINET EXHAUST FAN 42 IN 208-230/460 V by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$3,021.65 each $3,251.68 Savings: $230.03 (7%)
OEM#: 1AHD4CABINET EXHAUST FAN 42 IN 208-230/460 V by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$3,021.65 each
$3,251.68 Savings: $230.03 (7%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 1AHD4 Key Specs
Item
CABINET EXHAUST FAN 42 IN 208-230/460 V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
1AHD4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Assembly
Assembled
Bearing Type
Regreasable Cast Pillow Block
Blade Diameter
42 in
CFM @ 0.000 in SP
16,386 cfm
CFM @ 0.125 in SP
14,520 cfm
CFM @ 0.250 in SP
11,551 cfm
CFM @ 0.375 in SP
7,342 cfm
CFM @ 0.500 in SP
4,061 cfm
Country of Origin
Mexico
Drive Package With Motor Included
Yes
Drive Type
Belt
Exhaust/Supply Fan Item
Exhaust Fan
Exhaust/Supply Fan Motor HP
1 1/2 hp
Fan RPM
482
Fan Voltage
208-230/460V AC
Frame Material
Galvanized Steel
Full Load Amps
4.6-4.2/2.1
Green Certification or Other Recognition
NEMA Premium(R) Rated
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Height
46-1/4 in
Housing Material
Galvanized Steel
Hz
60
Includes
(4) Wall-Mounting Angles
Max Ambient Temperature
104 Degrees F
Max BHP
1.73 hp
Max Depth
34-5/8 in
Max Inlet Temperature
104 Degrees F
Motor Enclosure
Totally Enclosed Air-Over
Motor Insulation
Class F
Motor RPM
1,725 RPM
Motor Type
3-Phase
Mounting Position
Horizontal
Number of Blades
5
Phase
3
Propeller Material
Fabricated Steel
Sones @ 0.125 in SP @ 5 feet
21
Standards
AMCA Air, CSA Certified Motor, Sound, UL/cUL 705
Width
46-1/4 in
