OEM#: 1A398New OEM Original Outright

2 BOLT FLANGE BEARING, BEARING INSERT MATERIAL ALLOY STEEL, BEARING INSERT TYPE RADIAL BALL, BORE DIAMETER 3/4 IN, BORE TYPE CYLINDRICAL, CL by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$42.10 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO1A398
2 BOLT FLANGE BEARING, BEARING INSERT MATERIAL ALLOY STEEL, BEARING INSERT TYPE RADIAL BALL, BORE DIAMETER 3/4 IN, BORE TYPE CYLINDRICAL, CL by DAYTON ELECTRIC MANUFACTURING CO
2 BOLT FLANGE BEARING, BEARING INSERT MATERIAL ALLOY STEEL, BEARING INSERT TYPE RADIAL BALL, BORE DIAMETER 3/4 IN, BORE TYPE CYLINDRICAL, CL by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 1A398
2 BOLT FLANGE BEARING, BEARING INSERT MATERIAL ALLOY STEEL, BEARING INSERT TYPE RADIAL BALL, BORE DIAMETER 3/4 IN, BORE TYPE CYLINDRICAL, CL by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$42.10 each

2 BOLT FLANGE BEARING, BEARING INSERT MATERIAL ALLOY STEEL, BEARING INSERT TYPE RADIAL BALL, BORE DIAMETER 3/4 IN, BORE TYPE CYLINDRICAL, CLOSURE DOUBLE SEALED, EXPANSION TYPE FIXED, HOUSING MATERIAL ZINC DIE CAST, HOUSING TYPE RHOMBUS, LUBRICANT MATERIAL NLGI #2 EQUIVALENT, MAXIMUM SPEED 4,500 RPM, MAXIMUM TEMPERATURE 200 DEGREES F, MINIMUM TEMPERATURE -30 DEGREES F, MOUNT HOLE CENTER-TO-CENTER HEIGHT 2 13/16 IN, NUMBER OF MOUNT HOLES 2, OVERALL

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 1A398 Key Specs
Item
2 BOLT FLANGE BEARING, BEARING INSERT MATERIAL ALLOY STEEL, BEARING INSERT TYPE RADIAL BALL, BORE DIAMETER 3/4 IN, BORE TYPE CYLINDRICAL, CL
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
1A398
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Housing Material Type
Zinc Die Cast
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bolt Hole Center-to-Center
2 13/16 in
Bolt Size
5/16 in
Bore Dia.
3/4 in
Country of Origin
China
Dimension B
3 5/8 in
Dimension C
2 13/16 in
Dimension D
2 1/4 in
Dimension E
2 13/16 in
Dimension F
1 1/8 in
Dimension H
1/2 in
Dimension J
11/32 Sq.
Dimension L
1 1/8 in
Dynamic Load Capacity
2,877 lb
Finish
None
Includes
(2) Set Screws
Mounted Bearing Item
2-Bolt Flange Bearing
Overall Height
1 1/8 in
Overall Length
3 5/8 in
Overall Width
2 1/4 in
Series
F2DC-BL
Shaft Locking Type
Set Screw
Static Load Capacity
1,479 lb
Temp. Range
-30 Degrees to 200 Degrees F
