PCA EXHALATION FLOW INTERFACE BOARD FOR CARESCAPE™ R860, ENGSTRM VENTILATOR by Datex-Ohmeda
OEM#: 1505-5508-000PCA EXHALATION FLOW INTERFACE BOARD FOR CARESCAPE™ R860, ENGSTRM VENTILATOR by Datex-Ohmeda
Interface Board, PCA Exhalation Flow, For CARESCAPE™ R860, Engström Ventilator
Drop Shipped From GE - Not For Export Out Of US
The Printed Circuit Assembly (PCA) Exhalation Flow Interface Board is used in Engstrom ventilator, which is part of the respiratory care system. It is mounted on the outlet manifold panel assembly using compression spring and screws. This board is acting as an interface between the exhalation flow sensor board and the flow sensor through the connector interface cable. The flow sensor is a device used to monitor the airflow rate of a patient and measure the volume of gas dispensed from the O₂ and air channels during inhalation and exhalation. The PCA exhalation flow interface board is comprised of EMI filters, board mounted circular 4-position female connector, PCB and board mounted 8-contact female connector. This board is single layer with Electroless Nickel Immersion Gold (ENIG) finish. This board finish ensures solderability, and to protect the exposed copper circuitry. This board being used in Engstrom, ARC Testing Service, MS CARESCAPE™ Monitor B650, ARC Aestiva MRI, ARC Engstrom Carestation, ARC Light Monitor, Engstrom Pro, ARC Aspire 7900, MIC Panda™ ires Warmer, UL Voluson P8 and R860.
- Long shelf Life
- Hazardous materials are not used
- Meets international standards for safety requirements
- Electromagnetic Interference (EMI) protected
- Long shelf Life
- Hazardous materials are not used
- Meets international standards for safety requirements
- Electromagnetic Interference (EMI) protected
The Printed Circuit Assembly (PCA) Exhalation Flow Interface Board is used in Engstrom ventilator, which is part of the respiratory care system. It is mounted on the outlet manifold panel assembly using compression spring and screws. This board is acting as an interface between the exhalation flow sensor board and the flow sensor through the connector interface cable. The flow sensor is a device used to monitor the airflow rate of a patient and measure the volume of gas dispensed from the O₂ and air channels during inhalation and exhalation. The PCA exhalation flow interface board is comprised of EMI filters, board mounted circular 4-position female connector, PCB and board mounted 8-contact female connector. This board is single layer with Electroless Nickel Immersion Gold (ENIG) finish. This board finish ensures solderability, and to protect the exposed copper circuitry. This board being used in Engstrom, ARC Testing Service, MS CARESCAPE™ Monitor B650, ARC Aestiva MRI, ARC Engstrom Carestation, ARC Light Monitor, Engstrom Pro, ARC Aspire 7900, MIC Panda™ ires Warmer, UL Voluson P8 and R860.
- Long shelf Life
- Hazardous materials are not used
- Meets international standards for safety requirements
- Electromagnetic Interference (EMI) protected
- 1505-5508-000: GE Medical Systems Information Technology (GEMSIT)
- 1505-5508-000: GE Healthcare
- Datex-Ohmeda
- ENGSTROM
- R860
