12VDC ENHANCED SERIAL INTERFACE BOARD SUB ASSEMBLY FOR AESPIRE 7900 ANESTHESIA MACHINE by Datex-Ohmeda
OEM#: 1503-7014-00012VDC ENHANCED SERIAL INTERFACE BOARD SUB ASSEMBLY FOR AESPIRE 7900 ANESTHESIA MACHINE by Datex-Ohmeda
Assembly, Enhanced Serial Interface Board Sub, 12VDC Voltage Rating, For Aespire 7900 Anesthesia Machine
Drop Shipped From GE - Not For Export Out Of US
The Enhanced Serial Interface Board (ESIB) Sub Assembly 7900 Calibrated is an interface board for the Aespire 7900 ventilator. The ESIB serves as the link between the flow transducers, patient airway pressure transducer, manifold pressure transducer, oxygen sensor, drive pressure limit switch and the ventilator CPU board. The ESIB also passes through various switch positions to the ventilator CPU board. It provides an interface for the ACGO switch, the Bag/Vent switch, the canister release switch, control panel cover switch (ABS On/Off), CO₂ bypass switch and breathing circuit ID switches. AII the switch signals are filtered for Electromagnetic Interference (EMI) and from Electrostatic Discharge (ESD). The pressure transducers for measuring differential pressure are located on the ESIB. These are being used in UL Voluson P8, ARC Aespire View, MS CARESCAPE™ Monitor B850, ARC Aestiva 7100, ARC Engstrom Carestation, ARC Airway Gas Module, MS Dash™ 4000, ARC Aestiva 3000, MS PDM, Anesthesia Service Parts, MS TUFFSAT Oximeter, ARC Testing Service, MS CIC Pro, ARC Aestiva MRI, NM Xeleris WS 2.0, ARC Aisys, Aestiva 7900, Aestiva MRI, ARC Light Monitor and ARC Aespire 7900.
- Designed to use in Aespire 7900 anesthesia machine
- Voltage rating 12V DC
- RoHS compliant
The Enhanced Serial Interface Board (ESIB) Sub Assembly 7900 Calibrated is an interface board for the Aespire 7900 ventilator. The ESIB serves as the link between the flow transducers, patient airway pressure transducer, manifold pressure transducer, oxygen sensor, drive pressure limit switch and the ventilator CPU board. The ESIB also passes through various switch positions to the ventilator CPU board. It provides an interface for the ACGO switch, the Bag/Vent switch, the canister release switch, control panel cover switch (ABS On/Off), CO₂ bypass switch and breathing circuit ID switches. AII the switch signals are filtered for Electromagnetic Interference (EMI) and from Electrostatic Discharge (ESD). The pressure transducers for measuring differential pressure are located on the ESIB. These are being used in UL Voluson P8, ARC Aespire View, MS CARESCAPE™ Monitor B850, ARC Aestiva 7100, ARC Engstrom Carestation, ARC Airway Gas Module, MS Dash™ 4000, ARC Aestiva 3000, MS PDM, Anesthesia Service Parts, MS TUFFSAT Oximeter, ARC Testing Service, MS CIC Pro, ARC Aestiva MRI, NM Xeleris WS 2.0, ARC Aisys, Aestiva 7900, Aestiva MRI, ARC Light Monitor and ARC Aespire 7900.
