OEM#: 1500-3376-000New OEM Original Outright
DISPOSABLE ADAPTER OUTLET by Datex-Ohmeda
Your price:
$46.79 each
OEM#: 1500-3376-000DISPOSABLE ADAPTER OUTLET by Datex-Ohmeda
New OEM Original Outright
Your price:
$46.79 each
Asset Information
Drop Shipped From GE - Not For Export Out Of US
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
This Adapter Outlet, 30 mm Female to 19mm Male is being used in passive AGSS (Anesthesia Gas Scavenging Unit) of anesthesia machines. Passive AGSS is for use in operating room environments that do not have an active gas extraction system for waste disposal. The passive AGSS contains both positive and negative pressure relief valves to protect the breathing system. Passive AGSS may be used with a non-recirculating ventilation system for waste gas disposal. The tube connection from passive AGSS to the non-circulating ventilation system should be an open connection, essentially at atmospheric pressure. Hence the large diameter tube is connected to this 30 mm tapered connector on the bottom of the AGSS receiver. This adapter is made from a high strength, lightweight, polypropylene material that is magenta Munsell in color. Polypropylene is one of the most versatile polymers available with applications as both a plastic and as a fiber. This component is being used in ARC iVent 201, ARC Aestiva 7100, ARC Aespire 7900, ARC Aisys and few other anesthesia machine scavenging systems.
Features
- Free of grease, oil, mold release duct, lint or other obvious contamination
- High stiffness
- Heat resistant
- Chemical inertness
Technical Specs
P/N: 1500-3376-000 Key Specs
Item
DISPOSABLE ADAPTER OUTLET
OEM
Datex-Ohmeda
OEM #
1500-3376-000
Condition
New OEM Original
Returnable
No
Warranty
90 Day
Connection Data
30 to 19 mm
Inner Diameter
19 mm
Outer Diameter
30 mm
Usage
Disposable
Equivalents
Fitments
This Adapter Outlet, 30 mm Female to 19mm Male is being used in passive AGSS (Anesthesia Gas Scavenging Unit) of anesthesia machines. Passive AGSS is for use in operating room environments that do not have an active gas extraction system for waste disposal. The passive AGSS contains both positive and negative pressure relief valves to protect the breathing system. Passive AGSS may be used with a non-recirculating ventilation system for waste gas disposal. The tube connection from passive AGSS to the non-circulating ventilation system should be an open connection, essentially at atmospheric pressure. Hence the large diameter tube is connected to this 30 mm tapered connector on the bottom of the AGSS receiver. This adapter is made from a high strength, lightweight, polypropylene material that is magenta Munsell in color. Polypropylene is one of the most versatile polymers available with applications as both a plastic and as a fiber. This component is being used in ARC iVent 201, ARC Aestiva 7100, ARC Aespire 7900, ARC Aisys and few other anesthesia machine scavenging systems.
- 1500-3376-000: GE Healthcare: Canonical Redirect
- Datex-Ohmeda
- AESTIVA
- AISYS
- AISYS CS2
