OEM#: 4116090019New OEM Original Outright
AIR COMPRESSOR PUMP 2 STAGE 14 HP by Chicago Pneumatic
Your price:
$3,313.91 each
OEM#: 4116090019AIR COMPRESSOR PUMP 2 STAGE 14 HP by Chicago Pneumatic
New OEM Original Outright
Your price:
$3,313.91 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4116090019 Key Specs
Item
AIR COMPRESSOR PUMP 2 STAGE 14 HP
OEM
Chicago Pneumatic
OEM #
4116090019
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Avg. Pump Life
20,000 hr
Bore Dia.
2 1/16 in, 4 1/8 in
Construction
Cast Iron/Aluminum
Finish
Black Matt Painted
Flywheel Dia.
15 in
Flywheel Included
Yes
Free Air CFM @ Max. Pressure
16.6
Groove Quantity
2
Groove Section
A
HP
5 hp, 7 1/2 hp, 9 hp, 13 hp, 14 hp
Lubrication Type
Splash
Max. Pressure
175 psi
Mounting Pattern
9-1/4 in W x 6-37/64 in D
NPT Outlet
1 in
Number of Cylinders
2
Number of Stages
2
Oil Capacity
1.09 qt
Overall Depth
13 15/32 in
Overall Height
23 in
Overall Width
15 in
Pump RPM
1,400
Rotation
CCW
Sheave Size @ 1725 RPM
6 3/4 in
Sheave Size @ 3450 rpm
5 61/64 in
Stroke Length
3 in
Valve Material
Stainless Steel
Valve Type
Reed
