OEM#: 2SDX12-LTBS-P3/6New OEM Original Outright

WAFER CHECK VALVE IRON 2 FLANGE by Champion Spark Plug

Your price:
$449.44 eachReady to ship
HomeChampion Spark Plug2sdx12ltbsp36
WAFER CHECK VALVE IRON 2 FLANGE by Champion Spark Plug
WAFER CHECK VALVE IRON 2 FLANGE by Champion Spark Plug

OEM#: 2SDX12-LTBS-P3/6
WAFER CHECK VALVE IRON 2 FLANGE by Champion Spark Plug

New OEM Original Outright
Your price:
$449.44 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 2SDX12-LTBS-P3/6 Key Specs
Item
WAFER CHECK VALVE IRON 2 FLANGE
OEM
Champion Spark Plug
OEM #
2SDX12-LTBS-P3/6
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application - Valves
Process Piping
Body Material - Valves
Ductile Iron
Cap to Inlet Center
1-1/2 in
Connection Type - Check Valves
Flange x Flange
Country of Origin
China
Cracking Pressure - Check Valves
0.22 psi
Flow Design
Single
Item - Check Valves
Check Valve
Length
4-1/8 in
Max Steam Pressure - Valves
Not Rated
Max Water Pressure - Valves
250 psi @ 100 Degrees F
Maximum Temperature
250 Degrees F
Mechanism and Body Design
Inline Wafer
Mounting Orientation - Check Valves
Horizontal, Vertical
Overall Height
4-31/32 in
Pipe or Tube Size - Check Valves
2 in
Seal Material - Check Valves
Buna-N
Seat Material - Check Valves
Buna-N
Spring Material - Check Valves
316 Stainless Steel
Standards
API 594, API 598, ASME B16.42, ASME B16.5, ASTM A 351 Gr. CF8M, ASTM A 395 Gr. 60-40-18
Width
1-3/4 in
