OEM#: 10SDX15-SSVS-R2/5New OEM Original Outright

WAFER CHECK VALVE 316 SS 10 FLANGE by Champion Spark Plug

Your price:
$6,356.74 eachReady to ship
HomeChampion Spark Plug10sdx15ssvsr25
WAFER CHECK VALVE 316 SS 10 FLANGE by Champion Spark Plug
WAFER CHECK VALVE 316 SS 10 FLANGE by Champion Spark Plug

OEM#: 10SDX15-SSVS-R2/5
WAFER CHECK VALVE 316 SS 10 FLANGE by Champion Spark Plug

New OEM Original Outright
Your price:
$6,356.74 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 10SDX15-SSVS-R2/5 Key Specs
Item
WAFER CHECK VALVE 316 SS 10 FLANGE
OEM
Champion Spark Plug
OEM #
10SDX15-SSVS-R2/5
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application - Valves
Process Piping
Body Material - Valves
316 Stainless Steel
Cap to Inlet Center
1-1/2 in
Connection Type - Check Valves
Flange x Flange
Country of Origin
China
Cracking Pressure - Check Valves
0.23 psi
Flow Design
Single
Item - Check Valves
Check Valve
Length
13-3/8 in
Max Steam Pressure - Valves
Not Rated
Max Water Pressure - Valves
275 psi @ 100 Degrees F
Maximum Temperature
400 Degrees F
Mechanism and Body Design
Inline Wafer
Mounting Orientation - Check Valves
Horizontal, Vertical
Overall Height
13-3/32 in
Pipe or Tube Size - Check Valves
10 in
Seal Material - Check Valves
Viton
Seat Material - Check Valves
Viton
Spring Material - Check Valves
316 Stainless Steel
Standards
API 594, API 598, ASME B16.34, ASTM A 351 Gr. CF8M ASME B16.5
Width
3-1/8 in
