OEM#: 10X6-33710New OEM Original Outright

10FT CAT5E MOLDED BOOT ETHERNET CROSSOVER CABLE - RED by CableWholesale

Your price:
$5.74 eachReady to ship
HomeCableWholesale10X633710
10FT CAT5E MOLDED BOOT ETHERNET CROSSOVER CABLE - RED by CableWholesale
10FT CAT5E MOLDED BOOT ETHERNET CROSSOVER CABLE - RED by CableWholesale

OEM#: 10X6-33710
10FT CAT5E MOLDED BOOT ETHERNET CROSSOVER CABLE - RED by CableWholesale

New OEM Original Outright
Your price:
$5.74 each
Ready to ship
Asset Information

Lifetime Warranty

Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

This Cat5e 10 foot red crossover cable is used for networking, data transfer and phone lines. For use from a DSL/cable modem directly to the PC and for a direct link from PC to PC.

  • This particular cable is a red UTP (Unshielded Twisted Pair) patch cable with molded boots (snagless installation) and extra protection for the RJ45 connector and clip
  • The connectors are wired to the T568B standard
  • The individual conductors are 24 AWG (American wire gauge) stranded pure copper
  • Cat5e patch cables are stranded to improve flexibility
  • Pure copper conductors provide the best signal possible
  • The RJ45 plug features gold connectors to prevent corrosion thus ensuring a longer cable life

Features
  • This particular cable is a red UTP (Unshielded Twisted Pair) patch cable with molded boots (snagless installation) and extra protection for the RJ45 connector and clip
  • The connectors are wired to the T568B standard
  • The individual conductors are 24 AWG (American wire gauge) stranded pure copper
  • Cat5e patch cables are stranded to improve flexibility
  • Pure copper conductors provide the best signal possible
  • The RJ45 plug features gold connectors to prevent corrosion thus ensuring a longer cable life
Technical Specs
P/N: 10X6-33710 Key Specs
Item
10FT CAT5E MOLDED BOOT ETHERNET CROSSOVER CABLE - RED
OEM
CableWholesale
OEM #
10X6-33710
Condition
New OEM Original
Returnable
Yes
Warranty
Other (See Notes)
Color
Red
Conductor Color
Blue-White, Blue, Green-White, Green, Orange-White, Orange, Brown-White, Brown
Conductor Construction
0.19 MM
Conductor Diameter
0.58 MM
Conductor Material
Stranded Bare Copper
Connector
Cat5e Male Plug
Connector (Second End)
Cat5e Male Plug
Diameter
5.3mm
Gauge
24 AWG
Insulation Diameter
0.99 MM
Insulation Material
HD-PE
Jacket Material
Polyvinyl Chloride (PVC)
Length
10 FT
Number of Pairs
4
O.D (Outer Diameter)
5 ± 0.20 MM
Shielded/Unshielded
Unshielded
Standards
RoHS, UL, CSA, ETL, ANSI/TIA-568.2-D
