OEM#: SSF718-40K-B5-GS1New OEM Original Outright
SPEED REDUCER C-FACE 56C 40 1 by Boston Gear
Your price:
$3,369.65 each
OEM#: SSF718-40K-B5-GS1SPEED REDUCER C-FACE 56C 40 1 by Boston Gear
New OEM Original Outright
Your price:
$3,369.65 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: SSF718-40K-B5-GS1 Key Specs
Item
SPEED REDUCER C-FACE 56C 40 1
OEM
Boston Gear
OEM #
SSF718-40K-B5-GS1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Base
Optional
Bearings
Tapered Roller
Bore Dia.
5/8 in
Duty
Washdown
Finish
316 Stainless Steel
Frame
56C
Gear Material
Hardened and Ground Steel
Gear Type
Worm
Housing Material
316 Stainless Steel
Input RPM
1,750
Lubrication
Klubersynth UH1 6-460
Max. Input HP
0.3 hp
Max. Output Torque
355.0 in-lb
Mounting
Any Position
Nominal Output RPM
44
Nominal Ratio
40:1
Number of Stages
1
Output Shaft Dia.
7/8 in
Output Shaft Height
2 1/16 in
Output Torque @ 1/2 HP
355 in-lb
Output Torque @ 1/3 HP
266 in-lb
Overall Length
7.5 in
Overhung Load
600 lb
Pinion Material
Hardened Steel
Rotation
Forward/Reversible
Seal Type
Double Lip
Shaft Orientation
Right Angle
Single/Double Output/Universal
Single Output
Solid/Hollow Output Shaft
Solid
Speed Reducer Type
C-Face
Standards
NSF
Worm Center Distance
1.75 in
Worm Gear Material
Bronze
