OEM#: 4054BNew OEM Original Outright

SIGNAL GENERATOR 4.5 COLOR LCD 30 MHZ by B&K Precision

Your price:
$1,242.20 eachReady to ship
HomeB&K Precision4054B
SIGNAL GENERATOR 4.5 COLOR LCD 30 MHZ by B&K Precision
SIGNAL GENERATOR 4.5 COLOR LCD 30 MHZ by B&K Precision

OEM#: 4054B
SIGNAL GENERATOR 4.5 COLOR LCD 30 MHZ by B&K Precision

New OEM Original Outright
Your price:
$1,242.20 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4054B Key Specs
Item
SIGNAL GENERATOR 4.5 COLOR LCD 30 MHZ
OEM
B&K Precision
OEM #
4054B
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
AM Modulation
Internal/External
Country of Origin
China
Display
4.5 in Color LCD
FM Modulation
Internal/External
Frequency Dial Accuracy (%)
0-100
Impedance (Ohms)
50
Includes
AC Power Cord, Certificate of Calibration, USB Type A-To-Type B Cable
Interface
LAN, USBTMC (Standard), GPIB (Optional), USB Host Port
Other Types of Modulation
AM, DSB-AM, ASK, FM, FSK, PM, PSK, PWM
Other Waveform Range
Triangle Ramp 1 u Hz to 500 k Hz, Pulse 1 u Hz - 12 M Hz, Arbitrary 1 u Hz to 12.5 M Hz
Output Amplitude
2 mVpp to 10 Vpp Into 50 ohm (4 mVpp to 20 Vpp Into Open Circuit), 10 MHz 2 mVpp to 5 Vpp Into 50 ohm (4 mVpp - 10 Vpp Into Open Circuit)
Output Attenuation
+/-0.3dB
Power Source
AC Line Input (115/230 V AC, 50/60 Hz)
Sine Wave Distortion
DC - 10 MHz Less Than -60 dBc, 10 MHz to 30 MHz Less Than -50 dBc
Sine Wave Range
1 uHz to 30 MHz
Sine/Square Wave Accuracy
+/-25 PPM (1 yr)
Sq. Wave Rise/Fall Time (nS)
Less Than 12 ns (10%-90%) At Full Amplitude Into 50 ohm
Square Wave Range
1 uHz to 30 MHz
Sweep
Linear and Logarithmic, Up or Down
Sweep Range
Waveform Range Dependent
Sweep Rate
1 msec to 500 sec
Sweep Type
Continuous, Triggered, Gate or Burst
Type
Function/Arbitrary Waveform
