OEM#: F-PFD1-1204S34New OEM Original Outright
INDUSTRIAL HVLS FAN by Big Ass Fans
Your price:
$15,148.29 each
OEM#: F-PFD1-1204S34INDUSTRIAL HVLS FAN by Big Ass Fans
New OEM Original Outright
Your price:
$15,148.29 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: F-PFD1-1204S34 Key Specs
Item
INDUSTRIAL HVLS FAN
OEM
Big Ass Fans
OEM #
F-PFD1-1204S34
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Air Flow
83,490 cfm
Amps
2.36 A
Bearing Type
Permanently Lubricated, Double Sealed, SKF ball bearing
Blade Diameter
12 ft
Blade Finish
Anodized Aluminum
Blade Material
Aluminum
Country of Origin
USA
Coverage Area - Fans (Cooling) (sq ft)
2,500 sq ft
Coverage Area - Fans (Destratification) (sq ft)
2,500 sq ft
Down Rod Outside Dia.
36 in
Environmental Applications
Industrial
Fan Blade Color
Silver
Fan Housing Color
Yellow
Fan Mounting Location
I Beam, Spanning Trusses or Joists
Fan Watts
961 W
Housing Finish
Powder Coated
Hz
50/60 Hz
Includes
Airfoils, Controller, Drop Tube, Fan Motor Assembly, Mount, Safety Cable
Light Kit
None
Max. Ambient Temp.
131 Degrees F
Max. Mounting Height
27 ft
Min. Mounting Height
17 ft
Motor Design
Brushless Direct Drive
Motor Enclosure
Brushless Direct Drive
Motor HP
1 1/2 hp
Motor Insulation
Class F
Mount Type
Bracket
Number of Blades
6
Number of Speeds
Variable
Phase
3
RPM
147
Reversible
Yes
Sound Level
35 dBA
Speed Controllable - Fans
Yes
Standards
CSA Standard 22.2 No. 113, UL Standard 507
Thermal Protection
Auto
Voltage
380 to 480V AC
