OEM#: F-PFD1-1604S34New OEM Original Outright
INDUSTRIAL HVLS FAN by Big Ass Fans
Your price:
$14,787.22 each
OEM#: F-PFD1-1604S34INDUSTRIAL HVLS FAN by Big Ass Fans
New OEM Original Outright
Your price:
$14,787.22 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: F-PFD1-1604S34 Key Specs
Item
INDUSTRIAL HVLS FAN
OEM
Big Ass Fans
OEM #
F-PFD1-1604S34
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Airflow
139,635 cfm
Amps
3.39 A
Approvals, Certifications & Standards
CSA Standard 22.2 No. 113, UL Standard 507
Bearing Type
Permanently Lubricated, Double Sealed, SKF ball bearing
Blade Diameter
16 ft
Blade Finish
Anodized Aluminum
Blade Material
Aluminum
Country of Origin
USA
Coverage Area - Fans (Cooling) (sq ft)
15,000 sq ft
Coverage Area - Fans (Destratification) (sq ft)
15,000 sq ft
Downrod Outside Diameter
36 in
Environmental Applications
Industrial
Fan Blade Color
Silver
Fan Housing Color
Yellow
Fan Mounting Location
I Beam, Spanning Trusses or Joists
Fan Watts
1,469 W
Housing Finish
Powder Coated
Hz
50/60 Hz
Includes
Airfoils, Controller, Drop Tube, Fan Motor Assembly, Mount, Safety Cable
Light Kit
None
Maximum Ambient Temperature
131 Degrees F
Maximum Mounting Height
29 ft
Minimum Mounting Height
21 ft
Motor Design
Brushless Direct Drive
Motor Enclosure
Brushless Direct Drive
Motor Horsepower
1 1/2 hp
Motor Insulation
Class F
Mount Type
Bracket
Number of Blades
6
Number of Speeds
Variable
Phase
3
RPM
108
Reversible
Yes
Sound Level
35 dBA
Speed Controllable - Fans
Yes
Thermal Protection
Auto
Voltage
380 to 480V AC
