OEM#: F-PFD1-0804S34New OEM Original Outright
INDUSTRIAL HVLS FAN by Big Ass Fans
Your price:
$16,484.47 each
OEM#: F-PFD1-0804S34INDUSTRIAL HVLS FAN by Big Ass Fans
New OEM Original Outright
Your price:
$16,484.47 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: F-PFD1-0804S34 Key Specs
Item
INDUSTRIAL HVLS FAN
OEM
Big Ass Fans
OEM #
F-PFD1-0804S34
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Airflow
34,035 cfm
Amps
1.25 A
Approvals, Certifications & Standards
CSA Standard 22.2 No. 113, UL Standard 507
Bearing Type
Permanently Lubricated, Double Sealed, SKF ball bearing
Blade Diameter
8 ft
Blade Finish
Anodized Aluminum
Blade Material
Aluminum
Country of Origin
USA
Coverage Area - Fans (Cooling) (sq ft)
2,000 sq ft
Coverage Area - Fans (Destratification) (sq ft)
2,000 sq ft
Downrod Outside Diameter
36 in
Environmental Applications
Industrial
Fan Blade Color
Silver
Fan Housing Color
Yellow
Fan Mounting Location
I Beam, Spanning Trusses or Joists
Fan Watts
461 W
Housing Finish
Powder Coated
Hz
50/60 Hz
Includes
Airfoils, Controller, Drop Tube, Fan Motor Assembly, Mount, Safety Cable
Light Kit
None
Maximum Ambient Temperature
131 Degrees F
Maximum Mounting Height
25 ft
Minimum Mounting Height
12 ft
Motor Design
Brushless Direct Drive
Motor Enclosure
Brushless Direct Drive
Motor Horsepower
1 1/2 hp
Motor Insulation
Class F
Mount Type
Bracket
Number of Blades
6
Number of Speeds
Variable
Phase
3
RPM
202
Reversible
Yes
Sound Level
35 dBA
Speed Controllable
Yes
Thermal Protection
Auto
Voltage
380 to 480V AC
