OEM#: SA-2600New OEM Original Outright
FULLY AUTOMATED BLUETOOTH SAFETY ANALYZER by BC Group International, Inc. (BC Biomedical)
Your price:
$3,277.95 each
OEM#: SA-2600FULLY AUTOMATED BLUETOOTH SAFETY ANALYZER by BC Group International, Inc. (BC Biomedical)
New OEM Original Outright
Your price:
$3,277.95 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The BC Biomedical ModelSA-2600 is a fully automated microprocessor-based Electrical Safety Analyzer with built in Patient Simulator and Bluetooth technology. TheSA-2600 has fully customizable autosequence allowing for a full run-though of testing with limited user interaction. This release comes with a 4.3 inch color touchscreen, compatible with the MyBC Mobile App and allows for a multitude of tests to be performed on a device using the same unit and lead connections. It provides a full Electrical Safety Analyzer, as well as, ECG Simulation with four waveforms with constant QRS duration and six machine performance testing waveforms. There is Patient Lead testing for 10 inputs.
Features
- Custom and fixed autosequences
- LED status indicators
- Audible feedback
- Micro USB and Bluetooth communications
- Self-test points
- Externally replaceable ground fuse
- 4.3" color touchscreen
- Small, lightweight portable analyzer
- Line voltage measurement
- Device under test current measurement
- 200mA earth/ground lead resistance
- External leakage current
- Point-to-point testing
- Enclosure/chassis leakage current
- External resistance
- Source receptacle wiring integrity monitor
- MAP (isolation) function
- Internal ECG simulator
- True RMS readings
- AAMI ES1-1993 or IEC 60601 selectable test loads
- 90 to 264 VAC operation
- Touch controls keys - no knobs
Technical Specs
P/N: SA-2600 Key Specs
Item
FULLY AUTOMATED BLUETOOTH SAFETY ANALYZER
OEM
BC Group International, Inc. (BC Biomedical)
OEM #
SA-2600
Condition
New OEM Original
Returnable
No
Warranty
12 Month
Country of Origin
USA
Includes
Carrying Case - (Soft) - BC Biomedical Medium; Chassis Cable - 8 ft (BCB/Dale Type) - Black; Ground Lug with a Banana Jack Adapter; Fuse - SA 2000 Series - 250 mA 250V 5 x 20 mm; Safety Analyzer Protective Boot
Screen Size
4.3 in
The BC Biomedical ModelSA-2600 is a fully automated microprocessor-based Electrical Safety Analyzer with built in Patient Simulator and Bluetooth technology. TheSA-2600 has fully customizable autosequence allowing for a full run-though of testing with limited user interaction. This release comes with a 4.3 inch color touchscreen, compatible with the MyBC Mobile App and allows for a multitude of tests to be performed on a device using the same unit and lead connections. It provides a full Electrical Safety Analyzer, as well as, ECG Simulation with four waveforms with constant QRS duration and six machine performance testing waveforms. There is Patient Lead testing for 10 inputs.
