OEM#: IPA-3400-1New OEM Original Outright
INFUSION PUMP ANALYZER by BC Group International, Inc. (BC Biomedical)
Your price:
$7,412.62 each
OEM#: IPA-3400-1INFUSION PUMP ANALYZER by BC Group International, Inc. (BC Biomedical)
New OEM Original Outright
Your price:
$7,412.62 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
It is the most compact, full featured four channel analyzer on the market. It is a high accuracy, easy to use system that incorporates full touch screen control of all processes without the use of old fashioned buttons and knobs. This new cutting edge, Patented design uses a dual syringe stepper motor driven system that provides continuous monitoring of the fluid flow without the need to stop and perform intermittent drains like older technologies do. This provides a more realistic flow path for the Infusion Device under test and therefore more accurate readings. Also, independent stepper motor control of the custom designed ceramic valving allows the system to run not only more quietly and more smoothly, but it also allows for a bidirectional powered fluid flow for use in the built-in cleaning cycle.
Features
- The IPA-3400 has built-in auto-sequence capabilities that allows the user to perform automatic test procedures. This allows specific test routines specified by various manufacturers to be run, which provides a significant time savings as well as redu
- All test results are stored internally in the large 32 GB memory. They can also be downloaded to a USB flash drive or directly to a PC.
- There are specific requirements in IEC 60601-2-24 for not only flow readings but back pressure simulation, bolus (PCA) measurements and occlusion alarm monitoring. All of these features are specifically built into the IPA-3400 with simple to use on s
- The IPA-3400 is designed to hold up to 4 IPA-3900-FM flow modules. These modules are individually serialized and calibrated so that they may be moved from channel to channel and even unit to unit. Once installed they are recognized by the IPA-3400 an
- The interchangeable modules provide the user with unprecedented flexibility in their IPA Testing System. There is no need to be down when the unit is due for calibration. Only the modules need to be calibrated. This also allows the rotating of module
- The IPA-3400 display may be raised to gain full access to the four user swappable flow modules. No wiring or plumbing is required for module installation. Simply lift the display, remove the cover plate, loosen the retainer screw and slide the module
- The IPA-3400 allows for easy field expansion. You can buy a 1 channel unit and later purchase additional modules that can be added in the field. Just plug them in and the system will automatically recognize the additional module(s), reconfigure itsel
- Smaller in Size - Larger in Features. Faster in Operation. Easier To Use. High Accuracy. 1,2,3 and 4 Channel Models Available (Field Upgradeable). User Swappable Fully Self Contained Flow Modules. Calibration in Flow Modules. No Need To be Down For C
Technical Specs
P/N: IPA-3400-1 Key Specs
Item
INFUSION PUMP ANALYZER
OEM
BC Group International, Inc. (BC Biomedical)
OEM #
IPA-3400-1
Condition
New OEM Original
Returnable
No
Warranty
12 Month
Compatible Products
Flash Drives; Barcode Scanners; Keyboard; Mouse; PC
Includes
Flow Module (IPA-3400-FM); IPA-3400 Accessory Kit (BC20-00161); NIST Traceable Calibration Certificate; BC Flow Software; Manual; Operator's
Memory Size
32 GB
Ports
4 USB Ports; 4 AUX Ports
Touch Screen Size
7 in
US Patent Number
10; 100; 282
It is the most compact, full featured four channel analyzer on the market. It is a high accuracy, easy to use system that incorporates full touch screen control of all processes without the use of old fashioned buttons and knobs. This new cutting edge, Patented design uses a dual syringe stepper motor driven system that provides continuous monitoring of the fluid flow without the need to stop and perform intermittent drains like older technologies do. This provides a more realistic flow path for the Infusion Device under test and therefore more accurate readings. Also, independent stepper motor control of the custom designed ceramic valving allows the system to run not only more quietly and more smoothly, but it also allows for a bidirectional powered fluid flow for use in the built-in cleaning cycle.
