OEM#: DPM-2100New OEM Original Outright
DIGITAL PRESSURE/VACCUM METER by BC Group International, Inc. (BC Biomedical)
Your price:
$1,840.16 each
OEM#: DPM-2100DIGITAL PRESSURE/VACCUM METER by BC Group International, Inc. (BC Biomedical)
New OEM Original Outright
Your price:
$1,840.16 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The microprocessor-based Digital Pressure Meter family. They measure both gas and liquid pressures and provide multiple engineering unit displays for the results. The DPM Plus and adds temperature measurement.
- YSI 700 temperature probe interface
- 0.0-100.0 C / 32.0-212.0 F temperature range
- 0.5% fs accuracy (temperature)
- Min/Max temperature value storage
- Min/Max pressure value storage
- RS-232 Serial Communications
- -13.50 to 100.00 psi range
- 0.1% fs accuracy (pressure)
- Pressure scales include psi, inH2O, cmH2O, and mmHg
- Digital calibration – no pots to turn
- 5 digit LCD plus scale indication
- Battery life display (0 to 100%)
- Programmable digital filter
- LCD contrast is software adjustable
- 16 bit pressure measurement
- Digital zero adjust
Features
- 16 bit pressure measurement, Digital zero adjust
- YSI 700 temperature probe interface
- Min/Max temperature value storage
- Min/Max pressure value storage
- 0.1% fs accuracy (pressure)
- Pressure scales include psi, inH2O, cmH2O, and mmHg
- Digital calibration-no pots to turn
- 5 digit lcd plus scale indication
- Battery life display (0 to 100%)
- Programmable digital filter, LCD contrast is software adjustable
Technical Specs
P/N: DPM-2100 Key Specs
Item
DIGITAL PRESSURE/VACCUM METER
OEM
BC Group International, Inc. (BC Biomedical)
OEM #
DPM-2100
Condition
New OEM Original
Returnable
Yes
Warranty
12 Month
AC Adapter
Yes
Accuracy
0.5%
Battery Life
80 H
Battery Type
Alkaline
Display
LCD
Length
4 IN
Maximum Pressure
120 PSI
Maximum/Minimum Capture
Yes
Pressure Range
-13.50 to 100 PSI
Pressure Rating
-13 to 100 psi
Serial Communications
RS-232
Temperature Accuracy
0.5% FS
Temperature Connector
YSI-700 1/4 IN
Temperature Range
0°C to 100°C
Temperature Rating
32 to 212 deg F
Volts
9 V
The microprocessor-based Digital Pressure Meter family. They measure both gas and liquid pressures and provide multiple engineering unit displays for the results. The DPM Plus and adds temperature measurement.
- YSI 700 temperature probe interface
- 0.0-100.0 C / 32.0-212.0 F temperature range
- 0.5% fs accuracy (temperature)
- Min/Max temperature value storage
- Min/Max pressure value storage
- RS-232 Serial Communications
- -13.50 to 100.00 psi range
- 0.1% fs accuracy (pressure)
- Pressure scales include psi, inH2O, cmH2O, and mmHg
- Digital calibration – no pots to turn
- 5 digit LCD plus scale indication
- Battery life display (0 to 100%)
- Programmable digital filter
- LCD contrast is software adjustable
- 16 bit pressure measurement
- Digital zero adjust
