OEM#: HX22MMNew OEM Original Outright

SPLIT TAPER BUSHING, H, 22 MM BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA by B&B Manufacturing

Your price:
$27.79 eachReady to ship
HomeB&B Manufacturinghx22mm
SPLIT TAPER BUSHING, H, 22 MM BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA by B&B Manufacturing
SPLIT TAPER BUSHING, H, 22 MM BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA by B&B Manufacturing

OEM#: HX22MM
SPLIT TAPER BUSHING, H, 22 MM BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA by B&B Manufacturing

New OEM Original Outright
Your price:
$27.79 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: HX22MM Key Specs
Item
SPLIT TAPER BUSHING, H, 22 MM BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA
OEM
B&B Manufacturing
OEM #
HX22MM
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bolt Circle Diameter
2 in
Bore Bushing Series
H
Bore Diameter
22 mm
Bore System of Measurement
Metric
Bushing Type
Split Taper
Country of Origin
USA
Fastener Tightening Torque
95 in-lb
Flange Thickness
1/4 in
Flange Type
Solid
For Shaft Type
Keyed
Includes
(2) Cap Screws
Keyway Depth
2.9 mm
Keyway Width
6 mm
Large Barrel Diameter
1.625 in
Length Less Flange
1 in
Material
Steel
Overall Diameter
2.5 in
Overall Length
1.25 in
Small Barrel Diameter
1.57 in
Taper
3/4 in Per ft
