OEM#: 0112-1110New OEM Original Outright

LIQUID LEVEL SWITCH 58 PSI BRASS by Barksdale

Your price:
$930.89 eachReady to ship
HomeBarksdale01121110
LIQUID LEVEL SWITCH 58 PSI BRASS by Barksdale
LIQUID LEVEL SWITCH 58 PSI BRASS by Barksdale

OEM#: 0112-1110
LIQUID LEVEL SWITCH 58 PSI BRASS by Barksdale

New OEM Original Outright
Your price:
$930.89 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 0112-1110 Key Specs
Item
LIQUID LEVEL SWITCH 58 PSI BRASS
OEM
Barksdale
OEM #
0112-1110
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Material
Brass
Contact Form
SPST
Electrical Connections
Screw Clamp
Float Diameter
0.71 in
Float Length
0.98 in
Float Material
Buna N
Float Position
Below
Float Rod Angle
90 Degrees
Float Specific Gravity
0.57
Float Travel
1-1/4 in
Height
13.98 in
Max Current
1A
Max Pressure
58 psi
Max Voltage
24
Mounting
Vertical Open tank
NEMA Rating
4
Operating Temperature Range
90 Degrees F Max.
Overall Length
24.01 in
Stem Length
22.64 in
Stem Material
Brass
Switch Function
Close on Rise
Tank Connection Size
1 in NPT
VA Rating
20
Width
1.06 in
