OEM#: ZDVSM4407T-4New OEM Original Outright
MOTOR, 200HP, 1800RPM, 3PH, 60HZ, 447T, TEFC, FOOT by BALDOR
Your price:
$53,804.68 each
OEM#: ZDVSM4407T-4MOTOR, 200HP, 1800RPM, 3PH, 60HZ, 447T, TEFC, FOOT by BALDOR
New OEM Original Outright
Your price:
$53,804.68 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 200HP,1800RPM,3PH,60HZ,447T,TEFC,FOOT,
Features:
- Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
- Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
- Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
- Continuous constant torque to zero speed
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Technical Specs
P/N: ZDVSM4407T-4 Key Specs
Item
MOTOR, 200HP, 1800RPM, 3PH, 60HZ, 447T, TEFC, FOOT
OEM
BALDOR
OEM #
ZDVSM4407T-4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
ZDVSM4407T-4
Brg-De-Afbma
90BC03J30X
Brg-Ode-Afbma
6318MCVL0241
C-Dimension Inches
48.13
Constant-Torq-Hertz
41.66736111
Country of Origin
USA
Drive End Flange
Standard
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
447T
Horsepower
200
Insulation Class
F
Is_Motor
Yes
Magnetizing-Current
75.6
Maximum-Rpm
3600
Motor Rpm 60Hz
1790
Motor-Base-Amps
226
Motor-Base-Hp
200
Motor-Base-Hz
60
Motor-Base-Rpm
1790
Motor-Base-Volts
460
Motor-Max-Amps
218
Motor-Max-Hp
200
Motor-Max-Hz
90
Motor-Max-Rpm
2685
Motor-Max-Volts
460
Phase
3
Poles
4
Reliance Number
W06548A A 001
Rotor-Inertia
70.1
Rpm
1790
Rpm Range
1701-1800
Service Factor
1
Spec. Number
P44G3249
Temp. Code
2
Type
P
Weight
2,275.00
Baldor-Reliance Motor, 200HP,1800RPM,3PH,60HZ,447T,TEFC,FOOT,
Features:
- Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
- Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
- Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
- Continuous constant torque to zero speed
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
