OEM#: ZDM2333TNew OEM Original Outright
MOTOR, 15HP, 1765RPM, 3PH, 60HZ, 256TC, 0936M, TEBC, F by BALDOR
Your price:
$9,541.39 each
OEM#: ZDM2333TMOTOR, 15HP, 1765RPM, 3PH, 60HZ, 256TC, 0936M, TEBC, F by BALDOR
New OEM Original Outright
Your price:
$9,541.39 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 15HP,1765RPM,3PH,60HZ,256TC,0936M,TEBC,F
Features:
Test stands, material handling, packaging equipment, printing presses, etc. Applications requiring adjustable speed operation with full torque from zero to base speed and constant horseposer to maximum speed.
Features:
- Full torque at zero speed
- 1000:1 constant torque range
- Totally Enclosed Non Ventilated (TENV) or Totally Enclosed Blower Cooled (TEBC)
- 1/3 thru 500 horsepower
- Cast Iron construction
- C-Face with base 143TC thru 449TC
- Base mount only in frames 5007L-5009L
- Class H Insulated
- ISR® (Inverter Spike Resistant) magnet wire
- Meets NEMA MG 1, Part 31
Test stands, material handling, packaging equipment, printing presses, etc. Applications requiring adjustable speed operation with full torque from zero to base speed and constant horseposer to maximum speed.
Technical Specs
P/N: ZDM2333T Key Specs
Item
MOTOR, 15HP, 1765RPM, 3PH, 60HZ, 256TC, 0936M, TEBC, F
OEM
BALDOR
OEM #
ZDM2333T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
ZDM2333T
Bearing-Drive-End
6309
C-Dimension Inches
33.07
Country of Origin
USA
Design Code
B
Drive End Flange
C-Face
Enclosure
TEBC
Enclosure Type
Totally Enclosed
Fl Amps
37/18.5
Fl Efficiency
92.4
Frame
256TC
Hertz
60
Horsepower
15
Insulation Class
H
Is_Motor
Yes
Magnetizing-Current
16.6/8.3
Maximum-Rpm
5000
Motor Rpm 60Hz
1765
Mounting
Rigid
Opposite End Bearing
6208
Phase
3
Poles
4
Rotor-Inertia
1.57
Rpm
1765
Rpm Range
1701-1800
Service Factor
1
Slip-Hertz
1.2
Spec. Number
09F279X717Z1
Voltage
230/460
Weight
301
Baldor-Reliance Motor, 15HP,1765RPM,3PH,60HZ,256TC,0936M,TEBC,F
Features:
Test stands, material handling, packaging equipment, printing presses, etc. Applications requiring adjustable speed operation with full torque from zero to base speed and constant horseposer to maximum speed.
Features:
- Full torque at zero speed
- 1000:1 constant torque range
- Totally Enclosed Non Ventilated (TENV) or Totally Enclosed Blower Cooled (TEBC)
- 1/3 thru 500 horsepower
- Cast Iron construction
- C-Face with base 143TC thru 449TC
- Base mount only in frames 5007L-5009L
- Class H Insulated
- ISR® (Inverter Spike Resistant) magnet wire
- Meets NEMA MG 1, Part 31
