OEM#: VUHL3519New OEM Original Outright

MOTOR, 1HP, 1725RPM, 1PH, 60HZ, 56C, 3524L, TEFC, F3, N by BALDOR

Your price:
$1,019.20 eachReady to ship
HomeBALDORvuhl3519
MOTOR, 1HP, 1725RPM, 1PH, 60HZ, 56C, 3524L, TEFC, F3, N by BALDOR
MOTOR, 1HP, 1725RPM, 1PH, 60HZ, 56C, 3524L, TEFC, F3, N by BALDOR

OEM#: VUHL3519
MOTOR, 1HP, 1725RPM, 1PH, 60HZ, 56C, 3524L, TEFC, F3, N by BALDOR

New OEM Original Outright
Your price:
$1,019.20 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 1HP,1725RPM,1PH,60HZ,56C,3524L,TEFC,F3,N

Features:
  • UL/CSA recognized and CE certified
  • CEUHM/VEUHM motors are Super-E® with NEMA Premium® efficiency
  • CUHM/VUHM motors are EPAct efficiency and all are inverter-ready
  • 143-145TY and 143-145TYC frame motors have a special base with 56, 143 and 145 slots used on OEM conveyors
  • 56-140 frames have low profile F3 top-mounted conduit box
  • 3 year warranty on Super-E® motors
Typical Applications:
Unit and baggage handling, conveyors, packaging equipment, machine tools, hoists, elevators and door operators.

Technical Specs
P/N: VUHL3519 Key Specs
Item
MOTOR, 1HP, 1725RPM, 1PH, 60HZ, 56C, 3524L, TEFC, F3, N
OEM
BALDOR
OEM #
VUHL3519
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
7
Ambient Temp C
40
Baldor Catalog Number
VUHL3519
Bearing-Drive-End
6205
C-Dimension Inches
13.22
Country of Origin
USA
Design Code
L
Drive End Flange
C-Face
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
12.8/7-6.4
Fl Efficiency
67
Frame
56C
Hertz
60
Horsepower
1
Insulation Class
F
Kva-Code
K
Motor Rpm 60Hz
1725
Mounting
No Mounting
Opposite End Bearing
6203
Phase
1
Poles
4
Power-Factor
73
Rpm
1725
Rpm Range
1701-1800
Service Factor
1.15
Specification Number
35X062X945G1
Voltage
115/208-230
Weight
34
Baldor-Reliance Motor, 1HP,1725RPM,1PH,60HZ,56C,3524L,TEFC,F3,N

Features:
  • UL/CSA recognized and CE certified
  • CEUHM/VEUHM motors are Super-E® with NEMA Premium® efficiency
  • CUHM/VUHM motors are EPAct efficiency and all are inverter-ready
  • 143-145TY and 143-145TYC frame motors have a special base with 56, 143 and 145 slots used on OEM conveyors
  • 56-140 frames have low profile F3 top-mounted conduit box
  • 3 year warranty on Super-E® motors
Typical Applications:
Unit and baggage handling, conveyors, packaging equipment, machine tools, hoists, elevators and door operators.
