OEM#: VEM3558T-5New OEM Original Outright
3-PHASE MOTOR, 2 HP, 1755 RPM, 145TC FRAME, C-FACE MOUNT, TEFC,575 VOLTS by BALDOR
Your price:
$1,409.68 each
OEM#: VEM3558T-53-PHASE MOTOR, 2 HP, 1755 RPM, 145TC FRAME, C-FACE MOUNT, TEFC,575 VOLTS by BALDOR
New OEM Original Outright
Your price:
$1,409.68 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance 3-Phase Motor, VEM3558T-5, 2 HP, 1755 RPM, 145TC Frame, C-Face Mount, TEFC, 575 Volts
Some general purpose applications require a motor that runs on 200 volt power. These 200 volt motors are stocked from 1 Hp to 50 Hp in TEFC, and 1 Hp to 100 Hp in ODP. Also available is an extensive line of 575 volt motors. The 575 volt motors are available in general purpose TEFC and ODP, Washdown, Severe Duty, IEEE-841, Explosion Proof, and Close-Coupled pump designs, in a variety of mounting configurations.
Features
Some general purpose applications require a motor that runs on 200 volt power. These 200 volt motors are stocked from 1 Hp to 50 Hp in TEFC, and 1 Hp to 100 Hp in ODP. Also available is an extensive line of 575 volt motors. The 575 volt motors are available in general purpose TEFC and ODP, Washdown, Severe Duty, IEEE-841, Explosion Proof, and Close-Coupled pump designs, in a variety of mounting configurations.
Features
- Heavy gauge steel and cast iron frames
- Ball bearings
- ISR® (Inverter Spike Resistant®) copper windings
- Low-loss electrical grade lamination steel
- Three year Warranty
- Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: VEM3558T-5 Key Specs
Item
3-PHASE MOTOR, 2 HP, 1755 RPM, 145TC FRAME, C-FACE MOUNT, TEFC,575 VOLTS
OEM
BALDOR
OEM #
VEM3558T-5
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6205
Bearing-Opp-Drive-End
6203
C-Dimension Inches
14.17
Country of Origin
USA
Design Code
B
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
2.4
Fl Efficiency
86.5
Frame
145TC
Hertz
60
Horsepower
2
Insulation Class
F
Is_Motor
Yes
Kva-Code
L
Motor Rpm 60Hz
1755
Mounting
C-Face Footless
Nameplate Rpm
1755
Phase
3
Power-Factor
73
Rpm Range
1701-1800
Service Factor
1.15
Spec. Number
35AA003M840G1
Type
200-575V Motor
Voltage
575
Baldor-Reliance 3-Phase Motor, VEM3558T-5, 2 HP, 1755 RPM, 145TC Frame, C-Face Mount, TEFC, 575 Volts
Some general purpose applications require a motor that runs on 200 volt power. These 200 volt motors are stocked from 1 Hp to 50 Hp in TEFC, and 1 Hp to 100 Hp in ODP. Also available is an extensive line of 575 volt motors. The 575 volt motors are available in general purpose TEFC and ODP, Washdown, Severe Duty, IEEE-841, Explosion Proof, and Close-Coupled pump designs, in a variety of mounting configurations.
Features
Some general purpose applications require a motor that runs on 200 volt power. These 200 volt motors are stocked from 1 Hp to 50 Hp in TEFC, and 1 Hp to 100 Hp in ODP. Also available is an extensive line of 575 volt motors. The 575 volt motors are available in general purpose TEFC and ODP, Washdown, Severe Duty, IEEE-841, Explosion Proof, and Close-Coupled pump designs, in a variety of mounting configurations.
Features
- Heavy gauge steel and cast iron frames
- Ball bearings
- ISR® (Inverter Spike Resistant®) copper windings
- Low-loss electrical grade lamination steel
- Three year Warranty
- Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.
