OEM#: VEBM3615TNew OEM Original Outright

MOTOR, 5HP, 1750RPM, 3PH, 60HZ, 184TC, 3643M, TEFC, F1 by BALDOR

Your price:
$3,772.07 eachReady to ship
HomeBALDORvebm3615t
MOTOR, 5HP, 1750RPM, 3PH, 60HZ, 184TC, 3643M, TEFC, F1 by BALDOR
MOTOR, 5HP, 1750RPM, 3PH, 60HZ, 184TC, 3643M, TEFC, F1 by BALDOR

OEM#: VEBM3615T
MOTOR, 5HP, 1750RPM, 3PH, 60HZ, 184TC, 3643M, TEFC, F1 by BALDOR

New OEM Original Outright
Your price:
$3,772.07 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

Baldor-Reliance Motor, 5HP,1750RPM,3PH,60HZ,184TC,3643M,TEFC,F1

Features:

  • Standard NEMA BA dimension
  • Spring set brake
  • Power off operation manual release
  • NEMA Premium® Efficiency and inverter-ready
  • 230/460V brakes are connected in conduit box
Typical Applications:
Machine tools, conveyors, door operators, speed reducers, any application requiring quick stops and positive hold.

Technical Specs
P/N: VEBM3615T Key Specs
Item
MOTOR, 5HP, 1750RPM, 3PH, 60HZ, 184TC, 3643M, TEFC, F1
OEM
BALDOR
OEM #
VEBM3615T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
13.9
Ambient Temp C
40
Bearing-Drive-End
6206
Brake Rating
25
C-Dimension Inches
23.06
Country of Origin
USA
Design Code
B
Doe-Code
010A
Drive End Flange
C-Face
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
13.9-13.4/6.7
Fl Efficiency
89.5
Frame
184TC
Hertz
60
Horsepower
5
Insulation Class
F
Kva-Code
J
Motor Rpm 60Hz
1750
Mounting
C-Face Footless
Opposite End Bearing
6205
Phase
3
Poles
4
Power-Factor
78
Rpm
1750
Rpm Range
1701-1800
Service Factor
1.15
Spec. Number
36E049S268G1
Voltage
208-230/460
Weight
104

Baldor-Reliance Motor, 5HP,1750RPM,3PH,60HZ,184TC,3643M,TEFC,F1

Features:

  • Standard NEMA BA dimension
  • Spring set brake
  • Power off operation manual release
  • NEMA Premium® Efficiency and inverter-ready
  • 230/460V brakes are connected in conduit box
Typical Applications:
Machine tools, conveyors, door operators, speed reducers, any application requiring quick stops and positive hold.
