OEM#: M3112-57New OEM Original Outright
50 HERTZ MOTOR, 3 PH, 0.75 HP, 1425 IP23 RPM, 230/400 VOLTS, OPEN,56 FRAME by BALDOR
Your price:
$761.31 each
OEM#: M3112-5750 HERTZ MOTOR, 3 PH, 0.75 HP, 1425 IP23 RPM, 230/400 VOLTS, OPEN,56 FRAME by BALDOR
New OEM Original Outright
Your price:
$761.31 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance 50 Hertz Motor, M3112-57, 3 PH, 0.75 HP, 1425 IP23 RPM, 230/400 Volts, OPEN, 56 Frame
Some applications require NEMA motors which operate on true 50 Hz power. Where this 50 Hz power is all that is available, these NEMA motors are designed to be used at rated voltages with tolerance of ± 15% on voltage.
Some applications require NEMA motors which operate on true 50 Hz power. Where this 50 Hz power is all that is available, these NEMA motors are designed to be used at rated voltages with tolerance of ± 15% on voltage.
Technical Specs
P/N: M3112-57 Key Specs
Item
50 HERTZ MOTOR, 3 PH, 0.75 HP, 1425 IP23 RPM, 230/400 VOLTS, OPEN,56 FRAME
OEM
BALDOR
OEM #
M3112-57
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6203
Bearing-Opp-Drive-End
6203
C-Dimension Inches
10.12
Country of Origin
USA
Design Code
B
Duty
Continuous
Enclosure
OPEN
Enclosure Type
Open/Drip Proof
Fl Amps
3.2/1.9
Fl Efficiency
70
Frame
56
Hertz
50
Horsepower
3/4
Insulation Class
F
Is_Motor
Yes
Kva-Code
K
Motor Rpm 50Hz
1425
Mounting
Rigid
Nameplate Rpm
1425
Phase
3
Power-Factor
58
Rpm Range
1401-1500
Service Factor
1.25
Spec. Number
34F779-2382G1
Type
50 Hertz Motor
Voltage
230/400
Baldor-Reliance 50 Hertz Motor, M3112-57, 3 PH, 0.75 HP, 1425 IP23 RPM, 230/400 Volts, OPEN, 56 Frame
Some applications require NEMA motors which operate on true 50 Hz power. Where this 50 Hz power is all that is available, these NEMA motors are designed to be used at rated voltages with tolerance of ± 15% on voltage.
Some applications require NEMA motors which operate on true 50 Hz power. Where this 50 Hz power is all that is available, these NEMA motors are designed to be used at rated voltages with tolerance of ± 15% on voltage.
