OEM#: JL3504ANew OEM Original Outright

MOTOR, .5HP, 1725RPM, 1PH, 60HZ, 56J, 3421L, TEFC, F1 by BALDOR

Your price:
$842.38 eachReady to ship
HomeBALDORjl3504a
MOTOR, .5HP, 1725RPM, 1PH, 60HZ, 56J, 3421L, TEFC, F1 by BALDOR
MOTOR, .5HP, 1725RPM, 1PH, 60HZ, 56J, 3421L, TEFC, F1 by BALDOR

OEM#: JL3504A
MOTOR, .5HP, 1725RPM, 1PH, 60HZ, 56J, 3421L, TEFC, F1 by BALDOR

New OEM Original Outright
Your price:
$842.38 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, .5HP,1725RPM,1PH,60HZ,56J,3421L,TEFC,F1

Features:
  • Diecast aluminum end plates with machined steel bearing seat insert.
Typical Applications:
Residential and industrial pumps, swimming pool pumps, etc.

Technical Specs
P/N: JL3504A Key Specs
Item
MOTOR, .5HP, 1725RPM, 1PH, 60HZ, 56J, 3421L, TEFC, F1
OEM
BALDOR
OEM #
JL3504A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
4.3
Ambient Temp C
40
Bearing-Drive-End
6203
Bearing-Opp-Drive-End
6203
C-Dimension Inches
10.29
Country of Origin
USA
Design Code
N
Drive End Flange
C-Face
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
7.4/3.7
Fl Efficiency
68
Frame
56J
Hertz
60
Horsepower
1/2
Insulation Class
B
Is_Motor
Yes
Kva-Code
J
Motor Rpm 60Hz
1725
Mounting
C-Face Footless
Phase
1
Poles
4
Power-Factor
66
Rpm
1725
Rpm Range
1701-1800
Service Factor
1.25
Spec. Number
34-3099-5593
Voltage
115/230
Weight
26
Baldor-Reliance Motor, .5HP,1725RPM,1PH,60HZ,56J,3421L,TEFC,F1

Features:
  • Diecast aluminum end plates with machined steel bearing seat insert.
Typical Applications:
Residential and industrial pumps, swimming pool pumps, etc.
