OEM#: JL1205ANew OEM Original Outright

PUMP MOTOR, 1 PHASE, 0.33 HP, 115/230 VOLTS, 3450 RPM, 60 HZ, OPEN, 56J by BALDOR

Your price:
$402.62 eachReady to ship
HomeBALDORjl1205a
PUMP MOTOR, 1 PHASE, 0.33 HP, 115/230 VOLTS, 3450 RPM, 60 HZ, OPEN, 56J by BALDOR
PUMP MOTOR, 1 PHASE, 0.33 HP, 115/230 VOLTS, 3450 RPM, 60 HZ, OPEN, 56J by BALDOR

OEM#: JL1205A
PUMP MOTOR, 1 PHASE, 0.33 HP, 115/230 VOLTS, 3450 RPM, 60 HZ, OPEN, 56J by BALDOR

New OEM Original Outright
Your price:
$402.62 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

Baldor-Reliance Pump Motor, JL1205A, 1 Phase, 0.33 HP, 115/230 Volts, 3450 RPM, 60 HZ, OPEN, 56J

Our pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion proof ratings. Applications for these run the gamut from swimming pool pumps to medium and high thrust in-line pumps used in water treatment plants. Horse powers range in size from 1/3 through 75 HP.

Features

  • Diecast aluminum end plates with machined steel bearing seat insert.
Application(s)
  • Residential and industrial pumps, swimming pool pumps, etc

Technical Specs
P/N: JL1205A Key Specs
Item
PUMP MOTOR, 1 PHASE, 0.33 HP, 115/230 VOLTS, 3450 RPM, 60 HZ, OPEN, 56J
OEM
BALDOR
OEM #
JL1205A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
JL1205A
Bearing-Drive-End
6203
Bearing-Opp-Drive-End
6203
C-Dimension Inches
11.89
Design Code
N
Duty
Continuous
Enclosure
OPEN
Enclosure Type
Open/Drip Proof
Fl Amps
6.2/3.1
Fl Efficiency
58
Frame
56J
Hertz
60
Horsepower
1/3
Insulation Class
B
Is_Motor
Yes
Kva-Code
L
Motor Rpm 60Hz
3450
Phase
1
Power-Factor
61
Rpm
3450
Rpm Range
3001-3600
Service Factor
1.75
Spec. Number
34F036-2534G4
Type
Pump Motor
Voltage
115/230

Baldor-Reliance Pump Motor, JL1205A, 1 Phase, 0.33 HP, 115/230 Volts, 3450 RPM, 60 HZ, OPEN, 56J

Our pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion proof ratings. Applications for these run the gamut from swimming pool pumps to medium and high thrust in-line pumps used in water treatment plants. Horse powers range in size from 1/3 through 75 HP.

Features

  • Diecast aluminum end plates with machined steel bearing seat insert.
Application(s)
  • Residential and industrial pumps, swimming pool pumps, etc
