OEM#: FDL3610TMNew OEM Original Outright

MOTOR, 3HP, 1750RPM, 1PH, 60HZ, 184T, 3640LC, TEFC, F1 by BALDOR

Your price:
$2,823.69 eachReady to ship
HomeBALDORfdl3610tm
MOTOR, 3HP, 1750RPM, 1PH, 60HZ, 184T, 3640LC, TEFC, F1 by BALDOR
MOTOR, 3HP, 1750RPM, 1PH, 60HZ, 184T, 3640LC, TEFC, F1 by BALDOR

OEM#: FDL3610TM
MOTOR, 3HP, 1750RPM, 1PH, 60HZ, 184T, 3640LC, TEFC, F1 by BALDOR

New OEM Original Outright
Your price:
$2,823.69 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 3HP,1750RPM,1PH,60HZ,184T,3640LC,TEFC,F1

Features:
  • Ball bearings, lubricated with high temperature moisture-resistant grease
  • Condensation drains
  • Gasketed cast conduit boxed
  • Farm duty epoxy paint for protection from harsh environments
  • 1.00 Service Factor
Typical Applications:
Wide variety of agri-duty and industrial applications.

Technical Specs
P/N: FDL3610TM Key Specs
Item
MOTOR, 3HP, 1750RPM, 1PH, 60HZ, 184T, 3640LC, TEFC, F1
OEM
BALDOR
OEM #
FDL3610TM
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6206
C-Dimension Inches
18.05
Country of Origin
USA
Design Code
L
Drive End Flange
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
15.5
Fl Efficiency
80
Frame
184T
Hertz
60
Horsepower
3
Insulation Class
F
Is_Motor
Yes
Kva-Code
M
Motor Rpm 60Hz
1750
Mounting
Rigid
Opposite End Bearing Size
6205
Phase
1
Poles
4
Power-Factor
76
Rpm
1750
Rpm Range
1701-1800
Service Factor
1
Spec. Number
36G236Y739
Voltage
230
Weight
93
Baldor-Reliance Motor, 3HP,1750RPM,1PH,60HZ,184T,3640LC,TEFC,F1

Features:
  • Ball bearings, lubricated with high temperature moisture-resistant grease
  • Condensation drains
  • Gasketed cast conduit boxed
  • Farm duty epoxy paint for protection from harsh environments
  • 1.00 Service Factor
Typical Applications:
Wide variety of agri-duty and industrial applications.
