OEM#: EM3710TNew OEM Original Outright
MOTOR 3-PH 7-1/2 HP 1770 RPM 213T TEFC by BALDOR
Your price:
$1,318.60 each $1,673.41 Savings: $354.81 (21%)
OEM#: EM3710TMOTOR 3-PH 7-1/2 HP 1770 RPM 213T TEFC by BALDOR
New OEM Original Outright
Your price:
$1,318.60 each
$1,673.41 Savings: $354.81 (21%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: EM3710T Key Specs
Item
MOTOR 3-PH 7-1/2 HP 1770 RPM 213T TEFC
OEM
BALDOR
OEM #
EM3710T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC031A
Duty
Continuous
Frame
213T
Full Load Amps
18.8/9.4
HP
7-1/2 hp
Hz
60
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
15-1/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1770
Nominal Efficiency
91.7 %
Number of Speeds
1
Overall Length
19 in
Phase
3
RPM Group
1701-1800
RPM Range
1701-1800
Shaft Diameter
1-3/8 in
Shaft Length
3-3/8 in
Standards
CSA, UL
Voltage
230/460
