OEM#: EM3709TNew OEM Original Outright

MOTOR, 7.5HP, 3525RPM, 3PH, 60HZ, 213T, 3733M, TEFC, F by BALDOR

Your price:
$2,528.98 eachReady to ship
HomeBALDORem3709t
MOTOR, 7.5HP, 3525RPM, 3PH, 60HZ, 213T, 3733M, TEFC, F by BALDOR
MOTOR, 7.5HP, 3525RPM, 3PH, 60HZ, 213T, 3733M, TEFC, F by BALDOR

OEM#: EM3709T
MOTOR, 7.5HP, 3525RPM, 3PH, 60HZ, 213T, 3733M, TEFC, F by BALDOR

New OEM Original Outright
Your price:
$2,528.98 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 7.5HP,3525RPM,3PH,60HZ,213T,3733M,TEFC,F

Features:
  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
Typical Applications:
Pumps, compressors, fans, conveyors, machine tools and other applications where three phase power is available.

Technical Specs
P/N: EM3709T Key Specs
Item
MOTOR, 7.5HP, 3525RPM, 3PH, 60HZ, 213T, 3733M, TEFC, F
OEM
BALDOR
OEM #
EM3709T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
19.2
Ambient Temp C
40
Bearing-Drive-End
6307
Bearing-Opp-Drive-End
6206
C-Dimension Inches
17.89
Country of Origin
USA
Design Code
A
Doe-Code
010A
Drive End Flange
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
17.8/8.9
Fl Efficiency
91
Frame
213T
Hertz
60
Horsepower
7 1/2
Insulation Class
F
Is_Motor
Yes
Kva-Code
J
Motor Rpm 60Hz
3525
Mounting
Rigid
Nameplate Rpm
3525
Phase
3
Poles
2
Power-Factor
87
Rpm Range
3001-3600
Service Factor
1.15
Spec. Number
37H244Y216G1
Voltage
230/460
Weight
126
Baldor-Reliance Motor, 7.5HP,3525RPM,3PH,60HZ,213T,3733M,TEFC,F

Features:
  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
Typical Applications:
Pumps, compressors, fans, conveyors, machine tools and other applications where three phase power is available.
