OEM#: EM2539T-12New OEM Original Outright
GENERAL PURPOSE MOTOR, 230/460 V, 40 HP, 1770 RPM, 3 PH, 324T, OPSB by BALDOR
Your price:
$8,882.89 each
OEM#: EM2539T-12GENERAL PURPOSE MOTOR, 230/460 V, 40 HP, 1770 RPM, 3 PH, 324T, OPSB by BALDOR
New OEM Original Outright
Your price:
$8,882.89 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance General Purpose Motor, 230/460 V, 40 HP, 1770 RPM, 3 PH, 324T, OPSB
Baldor-Reliance's extensive line of General Purpose motors are available in Open Drip-proof and TEFC construction in both single and three phase. Horsepower sizes available from stock range from 1/12 HP through 1500 HP. Designed for General purpose use means that these motors can be used in applications which include compressors, pumps, fans, conveyors, material handling, machine tools and many others.
Features
Baldor-Reliance's extensive line of General Purpose motors are available in Open Drip-proof and TEFC construction in both single and three phase. Horsepower sizes available from stock range from 1/12 HP through 1500 HP. Designed for General purpose use means that these motors can be used in applications which include compressors, pumps, fans, conveyors, material handling, machine tools and many others.
Features
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty
- Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: EM2539T-12 Key Specs
Item
GENERAL PURPOSE MOTOR, 230/460 V, 40 HP, 1770 RPM, 3 PH, 324T, OPSB
OEM
BALDOR
OEM #
EM2539T-12
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
EM2539T-12
Bearing-Drive-End
6312
Bearing-Opp-Drive-End
6309
C-Dimension Inches
27.19
Country of Origin
USA
Design Code
A
Duty
Continuous
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Fl Amps
94/47
Fl Efficiency
94
Frame
324T
Grease
POLYREX EM
Hertz
60
Horsepower
40
Insulation Class
F
Is_Motor
Yes
Kva-Code
G
Motor Rpm 60Hz
1770
Mounting
Rigid
Nameplate Rpm
1770
Phase
3
Power-Factor
82
Rpm Range
1701-1800
Service Factor
1.15
Spec. Number
40E212X189
Type
General Purpose Motor
Voltage
230/460
Baldor-Reliance General Purpose Motor, 230/460 V, 40 HP, 1770 RPM, 3 PH, 324T, OPSB
Baldor-Reliance's extensive line of General Purpose motors are available in Open Drip-proof and TEFC construction in both single and three phase. Horsepower sizes available from stock range from 1/12 HP through 1500 HP. Designed for General purpose use means that these motors can be used in applications which include compressors, pumps, fans, conveyors, material handling, machine tools and many others.
Features
Baldor-Reliance's extensive line of General Purpose motors are available in Open Drip-proof and TEFC construction in both single and three phase. Horsepower sizes available from stock range from 1/12 HP through 1500 HP. Designed for General purpose use means that these motors can be used in applications which include compressors, pumps, fans, conveyors, material handling, machine tools and many others.
Features
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty
- Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
