OEM#: EFM2539TNew OEM Original Outright
MOTOR, 40HP, 1775RPM, 3PH, 60HZ, 324T, 4250M, OPSB, F2 by BALDOR
Your price:
$7,714.79 each
OEM#: EFM2539TMOTOR, 40HP, 1775RPM, 3PH, 60HZ, 324T, 4250M, OPSB, F2 by BALDOR
New OEM Original Outright
Your price:
$7,714.79 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 40HP,1775RPM,3PH,60HZ,324T,4250M,OPSB,F2
Features:
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Features:
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty.
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: EFM2539T Key Specs
Item
MOTOR, 40HP, 1775RPM, 3PH, 60HZ, 324T, 4250M, OPSB, F2
OEM
BALDOR
OEM #
EFM2539T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6312
Bearing-Opp-Drive-End
6309
C-Dimension Inches
26.69
Country of Origin
USA
Design Code
A
Doe-Code
010A
Drive End Flange
Standard
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Fl Amps
98/49
Fl Efficiency
94
Frame
324T
Grease
POLYREX EM
Hertz
60
Horsepower
40
Insulation Class
F
Is_Motor
Yes
Kva-Code
H
Motor Rpm 60Hz
1770
Mounting
Rigid
Nameplate Rpm
1770
Phase
3
Poles
4
Power-Factor
82
Rpm Range
1701-1800
Service Factor
1.15
Spec. Number
40H024X166G1
Voltage
230/460
Weight
477
